DELL Pro Max 18 Plus MB18250

Design

Colour name Magnetite

Product type Mobile workstation

Product colour Black

Form factor Clamshell

Intel® vPro™ Platform Eligibility Yes

Display

Display diagonal 45.7 cm (18")

Display resolution 2560 x 1600 pixels

Touchscreen No

HD type Quad HD+

Panel type WVA

Display technology marketing name ComfortView Plus

Native aspect ratio 16:10

Anti-glare screen Yes

Display brightness 500 cd/m²

Pixel density 168 ppi

RGB colour space DCI-P3

Colour gamut 100%

Display response rise/fall 30 ms

Maximum refresh rate 120 Hz

Contrast ratio (typical) 1000:1

Processor

Processor manufacturer Intel

Processor family Intel Core Ultra 7

Processor generation Intel Core Ultra (Series 2)

Processor model 265HX

Processor cores 20

Processor threads 20

Processor boost frequency 5.3 GHz

Performance cores 8

Efficient cores 12

Performance-core Max Turbo Frequency 5.3 GHz

Efficient-core Max Turbo Frequency 4.6 GHz

Performance-core base frequency 2.6 GHz

Efficient-core base frequency 2.3 GHz

Processor cache 30 MB

Processor base power 55 W

Maximum turbo power 160 W

Neural processor unit (NPU)

Neural processor unit (NPU) Intel AI Boost

Sparsity support Yes

Windows Studio effects support Yes

AI software frameworks supported by NPU DirectML, OpenVINO, Windows ML, ONNX RT, WebNN

Total processor performance up to 33 TOPs

NPU performance up to 13 TOPs

GPU performance up to 8 TOPs

Memory

Internal memory 32 GB

Internal memory type DDR5-SDRAM

Memory layout (slots x size) 2 x 16 GB

Maximum internal memory 64 GB

Memory channels Dual-channel

Memory data transfer rate 6400 MT/s

Non-ECC Yes

Storage

Total storage capacity 1 TB

Storage media SSD

Total SSDs capacity 1 TB

Number of SSDs installed 1

SSD capacity 1 TB

SSD memory type TLC

SSD interface PCI Express 4.0

NVMe Yes

SSD form factor M.2

Self-Encrypting Drive (SED) Yes

Optical drive type No

Card reader integrated Yes

Compatible memory cards SD, SDHC, SDXC

Graphics

Discrete GPU manufacturer NVIDIA

Discrete graphics card model NVIDIA RTX PRO 3000 Blackwell

Discrete graphics card memory 12 GB

Discrete graphics memory type GDDR7

On-board graphics card Yes

On-board GPU manufacturer Intel

Discrete graphics card Yes

On-board graphics card family Intel® Graphics

On-board graphics card model Intel® Graphics

Audio

Audio chip Cirrus Logic CS42L43

Number of built-in speakers 2

Speaker power 2.5 W

Built-in microphone Yes

Camera

Front camera Yes

Front camera resolution (numeric) 8.29 MP

Front camera resolution 1920 x 1080 pixels

Front camera HD type Full HD

Video capturing speed 30 fps

Infrared (IR) camera Yes

Privacy camera Yes

Privacy type Privacy shutter

Network

Top Wi-Fi standard Wi-Fi 7 (802.11be)

Mobile network connection No

Wi-Fi band Tri-band (2.4 GHz / 5 GHz / 6 GHz)

Wi-Fi data rate (max) 5760 Mbit/s

WLAN controller model Intel Wi-Fi 7 BE200

WLAN controller manufacturer Intel

Ethernet LAN Yes

Ethernet LAN data rates 10,1000,2500,100 Mbit/s

Bluetooth Yes

Near Field Communication (NFC) Yes

Ports & interfaces

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 2

Ethernet LAN (RJ-45) ports 1

HDMI ports quantity 1

HDMI version 2.1

Thunderbolt 4 ports quantity 1

Thunderbolt 5 ports quantity 2

Intel® Thunderbolt 4 Yes

Intel® Thunderbolt 5 Yes

Combo headphone/mic port Yes

USB Type-C DisplayPort Alternate Mode Yes

PowerShare Yes

Performance

Ambient light sensor Yes

Accelerometer Yes

Hall sensor Yes

Keyboard

Pointing device Touchpad

Numeric keypad Yes

Keyboard backlit Yes

Keyboard language UK English

Copilot key Yes

Software

Operating system architecture 64-bit

Trial software Activate Your Microsoft 365 For A 30 Day Trial

Operating system installed Windows 11 Pro

Brand-specific features

Brand specific technologies Express Charge Boost capable, TNR, HDR Camera, Control Vault 3+

Battery

Battery technology Lithium-Ion (Li-Ion)

Number of battery cells 6

Battery capacity 96 Wh

Battery voltage 11.7 V

Battery recharge time 3 h

Fast charging Yes

Power

USB Type-C charging port Yes

USB Type-C required charging power (min) 90 W

USB Power Delivery (USB PD) Yes

Security

Cable lock slot Yes

Cable lock slot type Noble

Fingerprint reader Yes

Smart card reader Yes

Trusted Platform Module (TPM) Yes

Trusted Platform Module (TPM) version 2.0

Dell ControlVault Yes

Operational conditions

Operating temperature (T-T) 0 - 35 °C

Storage temperature (T-T) -40 - 65 °C

Operating relative humidity (H-H) 10 - 90%

Storage relative humidity (H-H) 0 - 95%

Operating altitude -15.2 - 3048 m

Non-operating altitude -15.2 - 10668 m

Operating shock 110 G

Non-operating shock 160 G

Operating vibration 0.66 G

Non-operating vibration 1.3 G

Weight & dimensions

Width 402 mm

Depth 279.9 mm

Height (front) 1.79 cm

Height (rear) 1.96 cm

Weight 3.25 kg

Packaging content

AC adapter included No
