MiTAC B8261T85E24HR-2T - rack-mountable no CPU - SSD

B8261T85E24HR-2T - 635872057076

Brand: MITAC
Product code: B8261T85E24HR-2T
SKU: 1DCLT6W99RJOI
EAN/GTIN: 635872057076

Server
rack-mountable 2U
2-way
no CPU
NVMe
hot-swap 2.5" bay(s)
SSD
AST2600
Gigabit Ethernet, 10 Gigabit Ethernet
no OS
monitor: none
Weight: 33.22 KG

€5154.27 (Inc. VAT)

(Delivery 2-4 working days)

Product Info

The Mio MiTAC B8261T85E24HR-2T is a rack-mountable server designed for data centers with demands for performance and reliability. Featuring 24 hot-swap bays, this server allows for easy maintenance and upgrades, ensuring minimal downtime. It supports PCIe NVMe SSDs, enabling fast data access and transfer speeds. With a robust power supply of 2700 W and built-in redundancy, the server ensures continuous operation even in the event of power supply failure.

Operating within a temperature range of 10°C to 35°C and capable of handling high humidity levels, this server is engineered to operate in various environments. It comes equipped with essential connectivity options, including dual 10 Gigabit Ethernet ports and multiple USB interfaces. The motherboard is designed for scalability, supporting up to two processors, while the DDR5 SDRAM technology allows for memory speeds of up to 6000 MHz, meeting the needs of demanding applications.

Description

Robust memory capabilities

Equipped with 24 DDR5 SDRAM slots, this server supports high-speed memory of up to 6000 MHz, providing efficient performance for demanding tasks.

Efficient rack-mountable design

The Mio MiTAC B8261T85E24HR-2T features a rack-mountable chassis that optimizes space in server rooms, allowing for organized installations.

Comprehensive connectivity options

Dual 10 Gigabit Ethernet ports alongside multiple USB and VGA connections ensure flexible connectivity for various networking and peripheral needs.

Advanced temperature management

Temperature and voltage sensors monitor system health to maintain performance, helping to prevent overheating and hardware failure.

Future-ready storage flexibility

Supporting SSDs with PCIe NVMe interface allows for quick data handling, making this server suitable for enterprise applications that require swift data processing.

Specifications

General

Type Server

Internal Bays Qty 24

Front Accessible Bays Qty 24

Hot-Swap Bays Qty 24

Server Scalability 2-way

Product Form Factor Rack-mountable - 2U

Sensors Temperature sensor, voltage sensor

Built-in Devices 6 x hot-swap fans

Expansion / Connectivity

Interfaces 4 x USB 3.2 Gen 1 (2 front, 2 rear)1 x VGA - DB-152 x LAN (10Gigabit Ethernet) - RJ-451 x LAN (Gigabit Ethernet) - RJ-45

Slots 4 PCIe 5.0 x16

RAM

Effective Memory Speed 6000 MHz

Rated Memory Speed 6000 MHz

Slots 24 (Total) / 24 (empty)

Technology DDR5 SDRAM

Installed Size 6144 GB (max)

Networking

Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet

Remote Management Protocol IPMI 2.0

Ethernet Ports 2 x 10 Gigabit Ethernet, 1 x Gigabit Ethernet

Remote Management Controller Aspeed AST2600

Ethernet Controller Realtek RTL8211F

Miscellaneous

Compliant Standards FCC SDOC Class A, DOC-A, RoHS

Power

Device Type Power supply

Power Redundancy Yes

Voltage Required AC 100-127/200-240 V

Power Provided 2700 Watt

Power Redundancy Scheme 1+1

80 PLUS Certification 80 PLUS Titanium

Environmental Parameters

Min Operating Temperature 10 °C

Max Operating Temperature 35 °C

Humidity Range Operating 90% (non-condensing)

Optical Storage

Type No optical drive

Operating System / Software

OS Provided No operating system

Monitor

Monitor Type None.

Graphics Controller

Video Interfaces VGA

Graphics Processor ASPEED AST2600

Hard Drive

Type SSD - hot-swap

Interface Type PCI Express (NVMe) / U.2

Dimensions & Weight

Width 44.8 cm

Height 8.7 cm

Depth 85 cm

Processor / Chipset

Max CPU Qty 2

CPU Upgradability Upgradable

CPU No CPU

CPU Socket Socket SP5

Motherboard Name Tyan S8261GM2NE-2T
