HPE ConvergedSystem 240-HC StoreVirtual System
K2Q48A - 0888793999967
HP CS 240-HC StoreVirtual System
- Brand
- Hewlett Packard Enterprise
- Product code
- K2Q48A
- SKU
- B3R08HSK65IXF
- EAN/GTIN
- 0888793999967
- Management simplified
- Virtualization optimized
- Hyper-converged
€101134.87
(Inc. VAT)
Sold Out
(Delivery 2-4 working days)
Description
Management simplified
Designed from the ground up to simplify deployment of virtual infrastructure to support business-critical applications and virtual desktops. Features wizard-driven startup that enables complete deployment of virtualized compute and storage infrastructure in under 15 minutes. Centralized management of compute, storage, and virtual machines from inside VMware vCenter Server assures that an IT generalist can manage the entire virtual infrastructure from a single interface without any specialized storage, server or virtualization expertise. Pre-configured and only requires the entry of IP addresses, credentials, and VMware vSphere license information to get up and running.Virtualization optimized
Platform integration with VMware vSphere increases functionality and ease of use while application integration simplifies storage management for applications. Multiple clusters can be managed from the same console. Adding appliances to the cluster is quick and easy, with each additional appliance seamlessly adding the power of four servers and associated storage. Provides transparent VM failover across nodes, systems, and sites - bringing you worry-free protection in the event of a failure. Backup and recovery is equally easy with storage-based snapshots and HPE Remote Copy integration with virtualization platforms and Microsoft Windows applications. With built-in HPE Peer Motion, data volumes can non-disruptively replicate and migrate data volumes from one ConvergedSystem 200-HC to another, or to any x86-based server running any major hypervisor and HPE StoreVirtual VSA software. Pre-configured dashboards help visualize system health and performance while optional VMware vCenter Operations Manager (vCOPS) delivers VM-level insight.Hyper-converged
Features four individually serviceable servers in a 2U chassis with a choice between a hybrid, auto-tiering model with SAS and SSD capacity to serve performance and latency-sensitive workloads, or an all-SAS model to meet larger capacity requirements at a lower cost per capacity. With all you need in one box, the ConvergedSystem 200-HC serves both applications and data services with 4 times the compute in 75% less space. Provides scale-out flexibility to handle changing workloads while enabling simultaneous scale of server and storage resources. With over 1 million HPE StoreVirtual licenses issued, millions of virtual machines running on HPE ProLiant Servers, and over 30,000 HPE OneView for VMware vCenter downloads, customers can be confident that the ConvergedSystem 200-HC platform builds on proven virtualization expertise.Specifications
General
Device type
Hard drive array
Enclosure Type
Rack-mountable - 2U
Chassis
Installed Devices / Modules Qty
24
Supported Devices / Modules Qty
24
Supported Drives
SAS-2
Storage
Total Array Capacity
28.8 TB
HDD Array External Interface
10 Gigabit Ethernet
Processor
CPU
8 x Xeon E5-2640V2 2 GHz
RAM
Installed Size
512 GB
Storage Controller
Type
RAID
Installed Qty
4
Interface type
SAS 6Gb/s
Cache / Buffer Size (Max)
8 GB
RAID Level
RAID 0, RAID 5, RAID 6, RAID 10
Storage Controller (2nd)
Installed Qty
4
Hard drive
Type
HDD - hot-swap
Capacity
24 x 1.2 TB
Interface type
SAS 6Gb/s
Spindle Speed
10000 rpm
Features
Dual Port
Expansion / Connectivity
Expansion Bays
24 (total) / 0 (free) x hot-swap - 2.5" SFF
Interfaces
1 x serial 1 x USB 2.0 1 x VGA 1 x serial - RJ-45 4 x HPE iLO - RJ-45 8 x Ethernet 10Gb - SFP+
System requirements
OS Required
Microsoft Windows Server 2012
Miscellaneous
Features
80 PLUS Platinum Plus
Software included
VMware vSphere 5.5, VMware vCenter 5.5 with HP OneView
Compliant Standards
FCC Class A certified, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, EN55024, CISPR 22, FCC CFR47 Part 15, IEC 60950-1, EN 60950-1, WEEE, GB 9254, CNS 13438
Included Accessories
Rail kit
Power
Power Device
2 x internal power supply - hot-plug
Max Supported Qty
2
Power Redundancy
Yes
Voltage Required
AC 120/230 V
Power Provided
1500 Watt
Dimensions & Weight
Width
44.81 cm
Depth
82 cm
Height
8.74 cm
Weight
35.52 kg
Manufacturer Warranty
Service & Support
Limited warranty - parts - 3 years
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
30 °C
Humidity Range Operating
10 - 90% (non-condensing)
