QNAP TVS-AIH1688ATX-U7-32G NAS/storage server
TVS-AIH1688ATX-U7-32G - 4711103089811
QNAP TVS-AIH1688ATX-U7-32G NAS/storage server Tower 32 GB DDR5 0 TB QuTS hero Black
- Brand
- Qnap
- Product code
- TVS-AIH1688ATX-U7-32G
- SKU
- 7AIELN2WGZEHB
- EAN/GTIN
- 4711103089811
- Up to 36 TOPS AI performance: Integrated CPU, GPU, and NPU accelerate AI image applications, enabling faster facial and object recognition.
- 12+4 hybrid storage: Equipped with 12 SATA HDD bays and 4 U.2 NVMe / SATA SSD slots, balancing massive capacity with high-speed performance.
- Standard 2.5/10GbE, upgradeable to 100GbE: Expand via PCIe cards to 25/100GbE, ideal for virtualization, intensive file access, media transfer, and high-speed backup/restore tasks.
- Built-in Intel® Arc™ Graphics: Delivers outstanding graphics processing and compute performance to accelerate AI inference, media transcoding, and multitasking efficiency.
- Petabyte-scale expandability: Connect multiple QNAP JBODs to flexibly scale with business growth and store massive datasets or backups.
- Thunderbolt™ 5 expansion support: Optional Thunderbolt™ 5 PCIe card boosts workflows for professional multimedia editing.
Product Info
12 x 3.5" SATA 2/3, Intel Core Ultra 7, Intel Graphics, 32GB ECC UDIMM DDR5, 5GB OS, 2 x 10G LAN, 2 x 2.5G LAN, 2 x USB4 Type-C, 294.3 x 369.89 x 319.8 mm
QNAP TVS-AIH1688ATX-U7-32G. Type: NAS. Chassis type: Tower. Device class: Small & Medium Business. Internal memory: 32 GB, Internal memory type: DDR5. Total installed storage capacity: 0 TB. Operating system installed: QuTS hero
TVS-AIh1688ATX
Up to 36 TOPS, empower AI and virtualization workloads
The next-generation TVS-AIh1688ATX AI NAS is purpose-built for AI-driven image recognition and enterprise workloads. Powered by the high-performance Intel® Core™ Ultra processor with integrated compute, graphics, and neural processing units, it delivers stable performance while offloading AI inference tasks from the CPU. This reduces power consumption, improves efficiency, and accelerates intelligent image analysis. With its combination of robust processing power, large storage capacity, and flexible I/O expansion, the TVS-AIh1688ATX enables businesses to deploy a reliable storage solution while keeping budgets under control.
| Storage | |
|---|---|
| Supported storage drive interfaces | M.2, Serial ATA II, Serial ATA III |
| Storage drive sizes supported | 2.5,3.5,M.2 |
| Total installed system drives capacity | 5 GB |
| RAID support | Yes |
| RAID levels | 0, 1, 5, 6, 10, 50, 60, JBOD |
| Online RAID migration | Yes |
| Online RAID expansion | Yes |
| RAID rebuild | Yes |
| Hot-swap drive bays | Yes |
| Supported file systems | FAT32, HFS+, NTFS, exFAT, ext3, ext4 |
| Storage drives installed | No |
| Total installed storage capacity | 0 TB |
| Number of storage drives supported | 16 |
| Installed storage drive type | No |
| Supported storage drive types | HDD & SSD |
| Auto-rebuild | Yes |
| Bad block scan | Yes |
| Disk roaming | Yes |
| Processor | |
| Processor manufacturer | Intel |
| Processor boost frequency | 5.3 GHz |
| Processor cores | 20 |
| Processor threads | 20 |
| On-board graphics card model | Intel® HD Graphics |
| Memory | |
| Internal memory | 32 GB |
| Internal memory type | DDR5 |
| Memory form factor | UDIMM |
| Network | |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 2500,10000 Mbit/s |
| DHCP server | Yes |
| Jumbo frames support | Yes |
| Wake-on-LAN ready | Yes |
| Dynamic DNS (DDNS) | Yes |
| Ports & interfaces | |
| USB port | Yes |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 4 |
| Design | |
| Chassis type | Tower |
| Cooling type | Active |
| Product colour | Black |
| LED indicators | Yes |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Performance | |
| Type | NAS |
| Device class | Small & Medium Business |
| Backup function | Yes |
| Buzzer | Yes |
| Software | |
| Operating system installed | QuTS hero |
| Operating system version | h5.6.0 |
| Power | |
| Power supply location | Built-in |
| Power supply unit (PSU) capacity | 750 W |
| Number of power supply units | 1 |
| Power consumption (typical) | 130.83 W |
| Power consumption (HDD standby) | 97.036 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Weight & dimensions | |
| Width | 369.9 mm |
| Depth | 319.8 mm |
| Height | 294.3 mm |
| Weight | 13.8 kg |
| Package width | 440 mm |
| Package depth | 469 mm |
| Package height | 493 mm |
| Package weight | 17.2 kg |
| Packaging content | |
| Package type | Box |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage temperature (T-T) | -20 - 70 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Other features | |
| Warranty period | 5 year(s) |
