Lenovo ThinkCentre M90q Gen 5

12TT000KUK - 199273600878

Lenovo ThinkCentre M90q Gen 5 Intel® Core™ i7 i7-14700T 16 GB DDR5-SDRAM 512 GB SSD Windows 11 Pro Mini PC Black

Brand: Lenovo
Product Family: ThinkCentre
Product code: 12TT000KUK
SKU: X5POY1BP3JK4T
EAN/GTIN: 199273600878

Intel Core i7-14700T, 20C (8P + 12E)/28T, Max Turbo up to 5.2GHz, P-core 1.3/5.0GHz, E-core 0.9/3.7GHz, 33MB Intel Smart Cache
1x 16GB SODIMM DDR5-5600
512GB SSD M.2 2280 PCIe 4.0x4 NVMe Opal 2.0
Intel UHD Graphics 770
Windows 11 Pro

€1433.94 (Inc. VAT)

(Delivery 2-4 working days)

Intel Core i7-14700T, 20C (8P + 12E)/28T, Max Turbo up to 5.2GHz, P-core 1.3/5.0GHz, E-core 0.9/3.7GHz, 33MB Intel Smart Cache, 1x 16GB SODIMM DDR5-5600, 512GB SSD M.2 2280 PCIe 4.0x4 NVMe Opal 2.0, Intel UHD Graphics 770, Intel Wi-Fi 6E AX211 802.11ax 2x2 + BT5.3 vPro, Windows 11 Pro

Lenovo ThinkCentre M90q Gen 5. Processor frequency: 1.3 GHz, Processor family: Intel® Core™ i7, Processor model: i7-14700T. Internal memory: 16 GB, Internal memory type: DDR5-SDRAM, Memory clock speed: 5600 MHz. Total storage capacity: 512 GB, Storage media: SSD. On-board graphics card model: Intel UHD Graphics 770. Operating system installed: Windows 11 Pro. Power supply: 135 W. Chassis type: Mini PC. Product type: Mini PC. Weight: 1.25 kg. Product colour: Black

Specifications

Processor

Processor manufacturer Intel

Processor family Intel® Core™ i7

Processor model i7-14700T

Processor cores 20

Processor boost frequency 5 GHz

Processor frequency 1.3 GHz

Memory

Internal memory 16 GB

Maximum internal memory 64 GB

Internal memory type DDR5-SDRAM

Memory layout (slots x size) 1 x 16 GB

Memory slots 2x SO-DIMM

Memory clock speed 5600 MHz

Storage

Total storage capacity 512 GB

Storage media SSD

Optical drive type No

Total SSDs capacity 512 GB

Number of SSDs installed 1

SSD capacity 512 GB

SSD interface PCI Express 4.0

NVMe Yes

SSD form factor M.2

Card reader integrated No

Graphics

Discrete graphics card No

On-board graphics card Yes

Discrete graphics card model Not available

On-board GPU manufacturer Intel

On-board graphics card family Intel® UHD Graphics

On-board graphics card model Intel UHD Graphics 770

Network

Ethernet LAN Yes

Ethernet LAN data rates 100,1000 Mbit/s

Wi-Fi Yes

Top Wi-Fi standard Wi-Fi 6E (802.11ax)

Wi-Fi standards Wi-Fi 6E (802.11ax)

WLAN controller manufacturer Intel

WLAN controller model Intel Wi-Fi 6E AX211

Antenna type 2x2

Bluetooth Yes

Bluetooth version 5.3

Ports & interfaces

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 2

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 4

USB 3.2 Gen 2x2 Type-C ports quantity 1

HDMI ports quantity 1

HDMI version 2.1

DisplayPorts quantity 2

Ethernet LAN (RJ-45) ports 1

Combo headphone/mic port Yes

Design

Chassis type Mini PC

Volume 1 L

Cable lock slot Yes

Cable lock slot type Kensington

Product colour Black

Performance

Motherboard chipset Intel Q670

Audio chip Realtek ALC233

Audio system High Definition Audio

Number of speakers 1

Trusted Platform Module (TPM) Yes

Product type Mini PC

Software

Operating system language English

Operating system installed Windows 11 Pro

Power

Power supply 135 W

Certificates

Certification TCO,RoHS

Weight & dimensions

Width 179 mm

Depth 182.9 mm

Height 36.5 mm

Weight 1.25 kg

Packaging content

Mouse included Yes

Mouse connectivity Wired

Keyboard included Yes

Keyboard connectivity Wired
