Lenovo ThinkCentre M70q Gen 5

12TD009SUK - 0199274979676

Lenovo ThinkCentre M70q Gen 5 Intel® Core™ i5 i5-14500T 16 GB DDR5-SDRAM 512 GB SSD Windows 11 Pro Mini PC Black

Brand: Lenovo
Product Family: ThinkCentre
Product code: 12TD009SUK
SKU: NJJI8UGTRSSP1
EAN/GTIN: 0199274979676

Intel Core i5-14500T, 14C (6P + 8E)/20T, P-core 1.7/4.8GHz, E-core 1.2/3.4GHz, 24MB Intel Smart Cache
1x 16GB SODIMM DDR5-4800
512GB SSD M.2 2280 PCIe 4.0x4 NVMe Opal
Intel UHD Graphics 770
Windows 11 Pro

€1173.99 (Inc. VAT)

Sold Out

(Delivery 2-4 working days)

Intel Core i5-14500T, 14C (6P + 8E)/20T, P-core 1.7/4.8GHz, E-core 1.2/3.4GHz, 24MB Intel Smart Cache, 1x 16GB SODIMM DDR5-4800, 512GB SSD M.2 2280 PCIe 4.0x4 NVMe Opal, Intel UHD Graphics 770, Intel Wi-Fi 6E AX211 802.11ax 2x2 + BT5.3 vPro, Windows 11 Pro

Lenovo ThinkCentre M70q Gen 5. Processor frequency: 1.7 GHz, Processor family: Intel® Core™ i5, Processor model: i5-14500T. Internal memory: 16 GB, Internal memory type: DDR5-SDRAM, Memory clock speed: 4800 MHz. Total storage capacity: 512 GB, Storage media: SSD. On-board graphics card model: Intel UHD Graphics 770. Operating system installed: Windows 11 Pro. Power supply: 135 W. Chassis type: Mini PC. Product type: Mini PC. Weight: 1.25 kg. Product colour: Black

Specifications

Processor

Processor manufacturer Intel

Processor family Intel® Core™ i5

Processor model i5-14500T

Processor cores 14

Processor boost frequency 4.8 GHz

Processor frequency 1.7 GHz

Memory

Internal memory 16 GB

Maximum internal memory 64 GB

Internal memory type DDR5-SDRAM

Memory layout (slots x size) 1 x 16 GB

Memory slots 2x SO-DIMM

Memory clock speed 4800 MHz

Storage

Total storage capacity 512 GB

Storage media SSD

Optical drive type No

Total SSDs capacity 512 GB

Number of SSDs installed 1

SSD capacity 512 GB

SSD interface PCI Express 4.0

NVMe Yes

SSD form factor M.2

Card reader integrated No

Graphics

Discrete graphics card No

On-board graphics card Yes

Discrete graphics card model Not available

On-board GPU manufacturer Intel

On-board graphics card family Intel® UHD Graphics

On-board graphics card model Intel UHD Graphics 770

Performance

Motherboard chipset Intel Q670

Trusted Platform Module (TPM) Yes

Product type Mini PC

Network

Ethernet LAN Yes

Ethernet LAN data rates 100,1000 Mbit/s

Wi-Fi Yes

Top Wi-Fi standard Wi-Fi 6E (802.11ax)

Wi-Fi standards Wi-Fi 6E (802.11ax)

WLAN controller manufacturer Intel

WLAN controller model Intel Wi-Fi 6E AX211

Antenna type 2x2

Bluetooth Yes

Bluetooth version 5.3

Ports & interfaces

USB 2.0 ports quantity 1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 1

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity 1

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 4

DisplayPorts quantity 1

HDMI ports quantity 1

HDMI version 2.1

Ethernet LAN (RJ-45) ports 1

Combo headphone/mic port Yes

Power

Power supply 135 W

Design

Chassis type Mini PC

Volume 1 L

Cable lock slot Yes

Cable lock slot type Kensington

Product colour Black

Software

Operating system language English

Operating system installed Windows 11 Pro

Audio

Audio chip Realtek ALC233VB

Audio system High Definition Audio

Number of speakers 1

Weight & dimensions

Width 179 mm

Depth 182.9 mm

Height 36.5 mm

Weight 1.25 kg

Packaging content

Mouse included Yes

Mouse connectivity Wired

Keyboard included Yes

Certificates

Certification ENERGY STAR,TCO,EPEAT Silver,RoHS

Keyboard

Keyboard connectivity Wired
