KIOXIA CD8P-R Series KCD8XPUG30T7 - SSD - Data Centre, Read Intensive - 30720 GB - PCI Express 5.0 x4 (NVMe)

KCD8XPUG30T7 - 5054444716817

Brand: KIOXIA SSD
Product code: KCD8XPUG30T7
SKU: PKMU9VVZ0P57O
EAN/GTIN: 5054444716817

SSD
Data Centre, Read Intensive
30720 GB
internal
2.5"
PCI Express 5.0 x4 (NVMe)
Weight: 0.12 KG
Continuous operation capability ensures reliability and uptime for critical applications
High internal data rates up to 10,000 MBps read and 4,900 MBps write speeds
Comprehensive data protection with features like End-to-end data protection and PLP
Energy-efficient design with low power consumption in active and idle modes
Operational resilience across extreme temperature ranges and humidity levels

€16396.39 (Inc. VAT)

Sold Out

(Delivery 2-4 working days)

Product Info

The KIOXIA CD8P-R Series solid state drive is engineered to meet the needs of data centers and read-intensive applications. With a capacity of 30,720 GB and support for continuous operation, it offers reliability and endurance. The drive leverages BiCS5 flash technology and is compliant with NVMe 2.0 standards, ensuring high-speed data transfer rates of up to 10,000 MBps for reading and 4,900 MBps for writing.

Advanced features such as End-to-end data protection, Power Loss Protection (PLP), and Sanitize Instant Erase (SIE) provide robust security measures to protect your data. Additionally, the drive's efficient power management system minimizes energy consumption, making it both powerful and cost-effective. Designed to operate in a wide range of environmental conditions, the KIOXIA CD8P-R Series is the ideal choice for businesses seeking a durable, high-performance storage solution.

Description

Enhanced durability

Designed for continuous operation and equipped with BiCS5 flash technology, this solid state drive offers exceptional endurance and reliability for data centers and read-intensive applications.

High-speed performance

Boasting an internal data rate of up to 10,000 MBps for reading and 4,900 MBps for writing, the KIOXIA CD8P-R Series ensures swift data access and transfer speeds, enhancing overall system efficiency.

Advanced data protection

Features such as End-to-end data protection, Power Loss Protection (PLP), and Sanitize Instant Erase (SIE) provide comprehensive security measures to safeguard your data against various threats.

Efficient power management

With an active power consumption of 24 W and an idle power usage of just 5. 5 W, this SSD combines high performance with energy efficiency, reducing operational costs.

Robust environmental resilience

Capable of operating across a wide range of temperatures and humidity levels, this drive is built to withstand harsh conditions, ensuring consistent performance and longevity.

Specifications

General

Form Factor 2.5"

Weight 130 g

Height 15 mm

Width 69.85 mm

Device Type Solid state drive - internal

Depth 100.45 mm

NAND Flash Memory Type Triple-level cell (TLC)

Capacity 30720 GB

Interface PCI Express 5.0 x4 (NVMe)

Features 24x7 continuous operation, Open Compute Project 2.0, single port, Power Loss Protection (PLP), End-to-end data protection, Sanitize Instant Erase (SIE), BiCS5 flash, NVMe 2.0

Manufacturer Warranty

Service & Support Limited warranty - 5 years

Power

Power Consumption 24 Watt (active)5.5 Watt (idle)

Environmental Parameters

Min Operating Temperature 0 °C

Min Storage Temperature -40 °C

Max Storage Temperature 85 °C

Max Operating Temperature 72 °C

Shock Tolerance (operating) 1000 g @ 0.5 ms

Humidity Range Operating 5 - 95% RH

Vibration Tolerance (operating) 2.17 gRMS @ 5-800 Hz

Performance

Drive Writes Per Day (DWPD) 1

4KB Random Write 150000 IOPS

4KB Random Read 1600000 IOPS

Internal Data Rate 10000 MBps (read) / 4900 MBps (write)

Drive Class Data Centre, Read Intensive

Reliability

24x7 Operation Yes

MTBF 2,500,000 hours

Expansion & Connectivity

Compatible Bay 2.5"

Interfaces 1 x PCI Express 5.0 x4 (NVMe)
