iiyama TW1623AS-B3P computer monitor
iiyama TW1623AS-B3P computer monitor 39.6 cm (15.6") 1920 x 1080 pixels Full HD LED Touchscreen Black
- Brand
- Iiyama
- Product code
- TW1623AS-B3P
- SKU
- SKUVPSHS6676T
- EAN/GTIN
- 4948570126934
- Touchscreen 39.6 cm (15.6") LED IPS
- Full HD 1920 x 1080 pixels 16:9
- 30 ms 450 cd/m² 1000:1
- 9 W
€394.9
(Inc. VAT)
Sold Out
(Delivery 2-4 working days)
Product Info
iiyama TW1623AS-B3P. Display diagonal: 39.6 cm (15.6"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LED, Response time: 30 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 170°, Viewing angle, vertical: 170°. Built-in speaker(s). VESA mounting. Product colour: Black
The ProLite TW1623AS-B3P is a smart and intuitive 15.6" touch panel PC, designed for high-traffic environments such as meeting rooms, info points, or hospitality spaces. Its 10-point PCAP touch technology ensures smooth and precise interaction. Powered by Android 13, and equipped with powerful hardware, it allows easy installation of apps directly on the device - making it a all-in-one solution. Thanks to Power over Ethernet (PoE), both power and data are delivered through a single cable, simplifying installation and reducing additional cables. With a built-in microphone and speakers, the TW1623AS-B3P delivers seamless, modern interaction in any smart space. Additionally, it integrates effortlessly with iiSignage² , iiyama’s Content Management System (CMS), giving you full control over your messages and advertising, in landscape portrait and face-up position.
Description
Android OS
Thanks to Android OS, you can easily customize the display to your needs by installing applications directly to it.
iiSignage²
iiSignage² is our digital signage content management platform to easily show and control your content and to manage your displays in a secure way. The Content Management System (CMS) gives you total control of your messaging and advertising remotely and safely.
Connectivity
The RJ45 (LAN) connector supporting Power over Ethernet technology (POE) allows to provide both data connection and power by a single cable, which simplifies installation in areas where many cables would interfere with the environment.
| Display | |
|---|---|
| Display diagonal | 39.6 cm (15.6") |
| Display resolution | 1920 x 1080 pixels |
| HD type | Full HD |
| Native aspect ratio | 16:9 |
| Display technology | LED |
| Panel type | IPS |
| Touchscreen | Yes |
| Touchscreen technology | Projected capacitive system |
| Number of simultaneous touchpoints | 10 |
| Display brightness (typical) | 450 cd/m² |
| Display brightness | 385 cd/m² |
| Response time | 30 ms |
| Response time measurement type | GTG (Gray to Gray) |
| Contrast ratio (typical) | 1000:1 |
| Viewing angle, horizontal | 170° |
| Viewing angle, vertical | 170° |
| Display number of colours | 16.7 million colours |
| Pixel pitch | 0.1792 x 0.1792 mm |
| Viewable size, horizontal | 34.4 cm |
| Viewable size, vertical | 19.4 cm |
| Display diagonal (metric) | 39.5 cm |
| Surface hardness | 6H |
| Colour depth | 8 bit |
| Performance | |
| Operating hours (hours/days) | 24/7 |
| Operating system installed | Android |
| Operating system version | 13 |
| Multimedia | |
| Number of speakers | 2 |
| RMS rated power | 4 W |
| Built-in speaker(s) | Yes |
| Design | |
| Product colour | Black |
| Front bezel colour | Black |
| Glass thickness | 1.8 mm |
| Ports & interfaces | |
| USB version | 2.0 |
| USB Touch port | Yes |
| HDMI ports quantity | 1 |
| Mini HDMI ports quantity | 1 |
| Audio input | Mini Jack |
| Microphone in | Yes |
| HDCP | Yes |
| Card reader integrated | Yes |
| Compatible memory cards | SD |
| Network | |
| Wi-Fi | Yes |
| Wi-Fi standards | Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), 802.11g, 802.11a, 802.11b |
| Bluetooth | Yes |
| Bluetooth version | 5.2 |
| Ethernet LAN | Yes |
| Ergonomics | |
| VESA mounting | Yes |
| Panel mounting interface | 100 x 100 mm |
| Cable management | Yes |
| On Screen Display (OSD) | Yes |
| Power | |
| Power consumption (typical) | 9 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (off) | 0.3 W |
| AC adapter output voltage | 12 V |
| Power supply type | External |
| Weight & dimensions | |
| Width (with stand) | 387 mm |
| Depth (with stand) | 30.5 mm |
| Height (with stand) | 244 mm |
| Weight (with stand) | 1.5 kg |
| Packaging data | |
| Package width | 477 mm |
| Package depth | 75 mm |
| Package height | 298 mm |
| Package weight | 2.45 kg |
| Packaging content | |
| Power adapter included | Yes |
| Quick start guide | Yes |
| Sustainability | |
| Sustainability certificates | ErP |
| Other features | |
| AC adapter included | Yes |
| Placement supported | Indoor |
| Google applications | Google Chrome, Gmail, Google Calendar |
| Brightness | 385 cd/m² |
| Packaging content | AC adapter, interchangeable plugs (EU/UK) |
| Built-in processor | Yes |
| Active display area (W x H) | 344.2 x 193.6 mm |
| Multi-touch | Yes |
| USB ports quantity | 3 |
| Weight | 1.5 kg |
| User controls | Power switch, volume/ button +, volume/ button - |
| Touch method | finger, glove (latex), capacitive stylus |
| Height | 244 mm |
| Width | 387 mm |
| Control panel | Power switch, volume/ button +, volume/ button - |
| Compliance certificates | CE, EAC, REACH, RoHS, UKCA, WEEE |
| Ethernet LAN (RJ-45) ports | 1 |
| Certification | CE, EAC, RoHS support, ErP, WEEE, REACH, UKCA |
| Thin Client | |
| Processor family | ARM Rockchip |
| Processor model | RK3568 |
| Processor architecture | ARM Cortex-A55 |
| Processor frequency | 2 GHz |
| Processor cores | 4 |
