Cisco Integrated Services Router 1126X - router - DSL modem - desktop

C1126X-8PLTEP - 0889728190381

Brand: Cisco
Product code: C1126X-8PLTEP
SKU: TWFQM3W3NIIU2
EAN/GTIN: 0889728190381

Router
DSL modem 8-port switch
1GbE
Weight: 3.48 KG
Advanced connectivity
Intent-based networking
Integrated enterprise-class security
Easy management and deployment

€1171.89 (Inc. VAT)

Sold Out

(Delivery 2-4 working days)

Product Info

Get Internet access, advanced security, and wireless services in one device. Cisco 1000 Series Integrated Services Routers (ISRs) are fixed, high-performance routers that are easy to deploy and manage. Small yet powerful, they provide highly secure broadband, Metro Ethernet, and wireless LAN connectivity.

Description

Advanced connectivity

Get increased mobility and next-generation WAN and LAN options. Access Ethernet, DSL, LTE Advanced, and 802. 11ac Wi-Fi. The 1000 Series is ideal for use as customer premises equipment.

Intent-based networking

Manage and operate your WAN from a single dashboard. Provide highly secure, direct Internet access at the branch and optimize the user experience with Cisco SD-WAN.

Integrated enterprise-class security

Gain enterprise-class security and a highly secure WAN. Cisco Umbrella, Encrypted Traffic Analytics, and advanced threat defense provide high-performance encryption, VPN, firewall, and URL filtering.

Easy management and deployment

Use one operating system for consistency and visibility across all branch offices and remote sites. The 1000 Series is the first fixed-configuration router with Cisco's trusted IOS XE software.

Specifications

General

Enclosure Type Desktop

Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet

RAM 8 GB

Flash Memory 8 GB

Authentication Method RADIUS

Status Indicators Status

Connectivity Technology Wireless, wired

Device Type Router - 8-port switch (integrated)

Network / Transport Protocol IPSec, PPPoE, DHCP, DNS, L2TPv3

Routing Protocol OSPF, IS-IS, RIP-1, RIP-2, BGP, EIGRP, HSRP, DVMRP, VRRP, PIM-SM, static IP routing, IGMPv3, GRE, PIM-SSM, policy-based routing (PBR), MPLS, Bidirectional Forwarding Detection (BFD), RSVP

Remote Management Protocol SNMP, RMON, CLI, TR-069

Encryption Algorithm DES, Triple DES, SHA, MD5, IKE, ECDSA, 128-bit AES, 256-bit AES, 1024-bit RSA, 2048-bit RSA, 256-bit SHA, 512-bit SHA, 748-bit RSA, 384-bit SHA

Compliant Standards IEEE 802.3af, IEEE 802.11i, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at, IEEE 802.11r, CISPR 24, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, EN55024, CISPR 22, CB, EN 61000-6-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, EN 61000-4-5, EN 61000-4-11, FCC CFR47 Part 15, UL 60950-1 Second Edition, VCCI V-3, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, AS/NZS CISPR 22, CNS 13438, EN 301 489-7, EN 301 489-1, FCC CFR47 Part 22, FCC CFR47 Part 24, CAN/CSA C22.2 No. 60950-1 Second Edition, EN 300 386, EN 301 489-24, EN 301 908-1, EN 301 908-2, EN 301 511, EN 301 908-13

Features CBWFQ, WRED, ACL support, QoS, DMVPN, NetFlow, MRC, IPFIX, CSD, LISP, packet aggregation A-MPDU, packet aggregation A-MSDU, MIB II, AVC, AAA, DFS, ERSPAN, EEM

Expansion / Connectivity

Interfaces WAN: 1 x 1000Base-T/1000Base-X - RJ-45/SFPLAN: 4 x 1000Base-T - RJ-45LAN: 2 x 1000Base-T (PoE) - RJ-45LAN: 2 x 1000Base-T (PoE+) - RJ-45USB 3.0: 1 x console - 9 pin USB Type AConsole: 1 x RJ-45

Power

Power Device External power adapter

Voltage Required AC 120/230 V (50/60 Hz)

Environmental Parameters

Min Operating Temperature 0 °C

Max Operating Temperature 40 °C

Humidity Range Operating 5 - 95% (non-condensing)

Communications

Type DSL modem

Mobile Communication Protocol LTE

Digital Signaling Protocol ADSL2, VDSL2+, G.fast (Annex A)
