ATEN PE4102G power distribution unit (PDU)

PE4102G - 4711581520578

ATEN 2-Outlet Eco PDU Power Controller

Brand: ATEN
Product code: PE4102G
SKU: 9H7BZAEV61Q20
EAN/GTIN: 4711581520578

Local/remote control – On/Off/Cycle per outlet
Power-on sequencing – sets order & delay per port
Supports Auto Ping & Reboot
Remote control via TCP/IP & built-in 10/100 Ethernet port
Works with web-based eco DC software

€247.97 (Inc. VAT)

Sold Out

(Delivery 2-4 working days)

Product Info

2-Outlet Eco PDU Power Controller

ATEN 2-Outlet Eco PDU Power Controller. PDU types: Managed, Mounting type: Desk/Wall, Product colour: Black. AC outlets quantity: 2 AC outlet(s), AC outlet types: C13 coupler, Power plug: C14 coupler. Cable length: 3 m. Supported network protocols: TCP/IP, UDP, HTTP, HTTPS, SSL, SMTP, ARP, NTP, DNS, SNMP V1&V2&V3. Nominal input voltage: 100 - 240 V, Maximum current: 10 A, AC input frequency: 50 - 60 Hz

Engineered to be an intelligent power distribution solution, the PE4102G Eco PDU Power Controller ships with 2 power outlets in an IEC socket configuration. It provides secure, centralized, intelligent, and remote power management of data center IT equipment to minimize operating costs.

The PE4102G features the remote power control function, allowing you to control devices attached to the PDU at the PDU device level from practically any location via a TCP/IP connection. The power sequence design eliminates the risks of power inrush, guaranteeing reliable operation and protecting the overall system health. With the support for eco DC software, it provides an easy method for managing multiple devices, offering an intuitive and user-friendly Graphical User Interface that allows you to configure a PDU device and reboot the device in case any equipment lock-up occurs. Additionally, the auto ping and auto reboot functions ensure devices remain responsive by automatically detecting connection issues and rebooting when necessary. Administrators can switch on/off or set a delay time for each power outlet or individual power outlet group whenever, wherever.

The PE4102G boasts a slim, compact form factor and supports desk mount, wall mount, as well as rack mount, ensuring easy installation in confined spaces. It is a smart eco PDU power controller tailored for hospitality or retail applications, such as digital signage and video walls, for edge computing devices, including routers, servers, and cameras, or for any data center environments where there is no need to keep the servers powered on at all times.

Design
PDU types	Managed
Rack mounting	Yes
Mounting type	Desk/Wall
Product colour	Black
Ports & interfaces
AC outlets quantity	2 AC outlet(s)
Power plug	C14 coupler
AC outlet types	C13 coupler
Ethernet LAN (RJ-45) ports	1
Features
Cable length	3 m
Password protection	Yes
Management features
Supported network protocols	TCP/IP, UDP, HTTP, HTTPS, SSL, SMTP, ARP, NTP, DNS, SNMP V1&V2&V3
Power
Nominal input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Maximum current	10 A
Nominal output voltage	100 - 240 V
Load capacity	2400 VA
Certificates
Compliance certificates	Low Voltage Directive (LVD), CE, Electromagnetic Compatibility (EMC)
Operational conditions
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	0 - 80%
Weight & dimensions
Width	127.8 mm
Depth	170 mm
Height	44 mm
Weight	980 g
Packaging content
Cables included	AC
Manual	Yes
Packaging data
Package weight	1.27 kg
Package width	95 mm
Package depth	265 mm
Package height	220 mm
Package volume	5550.101932032 cm³
Logistics data
Country of origin	China
Master (outer) case net weight	4.9 kg
Master (outer) case width	232 mm
Master (outer) case length	500 mm
Master (outer) case height	283 mm
Master (outer) case gross weight	6.92 kg
Master (outer) case volume	32819.225200128 cm³
