ASUS RS501A-E12-RS4U
ASUS RS501A-E12-RS4U LGA 6096 Rack (1U) Black, Silver
- Brand
- Asus
- Product code
- 90SF03Y1-M002J0
- SKU
- XFOYUDRRYGEYR
- EAN/GTIN
- 4711387978535
- Powerful performance: Powered by AMD EPYC 9005 processors with 192 Zen 5c cores, 12-channel, up to 5200MHz DDR5 and support for a maximum TDP of up to 450 watts.
- Scale-up storage and expansion design: Up to four drives on the front panel and three PCIe 5.0 slots for higher bandwidth and system upgrades
- Flexible networking module design: Up to four all-flash 2.5” NVMe drives on the front panel and three PCIe 5.0 slots for higher bandwidth and system upgrades.
- Advanced air-cooling solution: Features enhanced-volume air-cooling (EVAC) heatsink for processors with higher TDP.
- Enhanced IT-infrastructure management: ASUS ASMB11-iKVM remote control with ASPEED AST2600, ASUS Control Center IT-management software and hardware-level Root-of-Trust solution.
- Read for AI and HPC workloads: Up to two single-slot GPUs.
€2848.3
(Inc. VAT)
Sold Out
(Delivery 2-4 working days)
Product Info
AMD EPYC™ 9005 single-processor 1U server that supports up to 24 DIMM, four NVMe, three PCIe® 5.0 slots, two M.2, OCP 3.0, two single-slot GPUs and ASUS ASMB11-iKVM.
ASUS RS501A-E12-RS4U. Processor socket: LGA 6096, Processor manufacturer: AMD, Processor family: AMD EPYC. Supported memory types: DDR5-SDRAM, Maximum internal memory: 3 TB, Supported RDIMM clock speeds: 4800,6400,5600 MHz. Storage drive sizes supported: M.2,2.5, Supported storage drive types: HDD & SSD, Supported storage drive interfaces: Serial ATA, Serial Attached SCSI (SAS). Ethernet interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, LAN controller: Intel® I350-AM2. Chassis type: Rack (1U), Product colour: Black, Silver, Certification: BSMI, CB, CE, RCM, FCC(Class A), ENERGY STAR®
AMD EPYC™ 9005 single-processor 1U server that supports up to 24 DIMM, four NVMe, three PCIe® 5.0 slots, two M.2, OCP 3.0, two single-slot GPUs and ASUS ASMB11-iKVM.
Faster storage, graphics and networking capabilities
PCI Express® (PCIe®) 5.0 delivers 32 GT/s bandwidth, which is twice the speed of PCIe 4.0, and offers lower power consumption, better land scalability and backwards compatibility. ASUS servers are PCIe 5.0 ready with scalability design to satisfy the increasing workloads for modern data centers.
| Processor | |
|---|---|
| Built-in processor | No |
| Processor socket | LGA 6096 |
| Processor manufacturer | AMD |
| Processor family | AMD EPYC |
| Number of processors supported | 1 |
| Compatible processor series | AMD EPYC 9004 |
| Memory | |
| Number of DIMM slots | 24 |
| Supported memory types | DDR5-SDRAM |
| Maximum internal memory | 3 TB |
| Supported RDIMM clock speeds | 4800,6400,5600 MHz |
| Storage | |
| Number of storage drives supported | 6 |
| Hot-swap HDD bays | Yes |
| Number of 2.5" bays | 4 |
| Storage drive sizes supported | M.2,2.5 |
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | Serial ATA, Serial Attached SCSI (SAS) |
| SSD form factor | M.2 |
| Network | |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| LAN controller | Intel® I350-AM2 |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 2 |
| VGA (D-Sub) ports quantity | 1 |
| Expansion slots | |
| PCI Express x16 (Gen 5.x) slots | 3 |
| Number of M.2 (M) slots | 2 |
| Design | |
| Chassis type | Rack (1U) |
| Product colour | Black, Silver |
| LED indicators | Yes |
| Certification | BSMI, CB, CE, RCM, FCC(Class A), ENERGY STAR® |
| Power | |
| Power supply | 1600 W |
| Redundant power supply (RPS) support | Yes |
| Number of redundant power supplies supported | 2 |
| 80 PLUS certification | 80 PLUS Titanium |
| Operational conditions | |
| Operating temperature (T-T) | 10 - 35 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 20 - 90% |
| Weight & dimensions | |
| Width | 842.5 mm |
| Depth | 449 mm |
| Height | 43.9 mm |
| Weight | 14.2 kg |
| Packaging data | |
| Package weight | 19.2 kg |
