Toshiba MG09 Series MG09SCA16TE - hard drive - 16 TB - SAS 12Gb/s
- Brand
- TOSHIBA HDD
- Product code
- MG09SCA16TE
- SKU
- 6OO4ZABCDVQQT
- EAN/GTIN
- 8592978563486
- Hard drive
- 16 TB
- internal
- 3.5"
- SAS 12Gb/s
- 7200 rpm
- buffer: 512 MB
- Weight: 0.70 KG
Product Info
The Toshiba MG09 Series hard drive is designed to meet the rigorous demands of enterprise-level applications. This 3.5" internal hard drive offers a substantial 16 TB capacity, making it an ideal solution for large-scale data storage challenges. Engineered for continuous 24x7 operation, it can handle a workload of up to 550 TB per year, ensuring dependable performance under heavy use conditions.
Featuring a helium sealed-drive design, the MG09 Series is built for durability and reliability, with a mean time between failures (MTBF) of 2,500,000 hours. It incorporates technologies such as Conventional Magnetic Recording (CMR) and Flux Control Microwave Assisted Magnetic Recording (FC-MAMR), alongside Persistent Write Cache technology, to provide secure and efficient data management. With a data transfer rate of 12 Gbit/s and a 512 MB buffer size, this hard drive delivers fast and reliable data access, making it a choice for businesses seeking high-capacity, high-performance storage solutions.
Description
Robust durability
Engineered to withstand the rigors of continuous operation, the Toshiba MG09 Series hard drive features a helium sealed-drive design and a high endurance rating of 600,000 load/unload cycles, ensuring reliability and durability in demanding operational environments.
High capacity storage
With a generous 16 TB capacity, this hard drive meets the needs of intensive data storage requirements, making it ideal for enterprise-level storage solutions.
Energy-efficient performance
The Toshiba MG09 Series is designed for efficiency, featuring a low power consumption of 8. 71 W during read/write operations and 4. 49 W during active idle, reducing operational costs.
Advanced data security
Incorporating Persistent Write Cache technology, the MG09 Series offers enhanced data integrity and security, safeguarding critical data against power loss or system failures.
Exceptional speed and reliability
Boasting a data transfer rate of 12 Gbit/s and a spindle speed of 7200 rpm, coupled with a substantial 512 MB buffer size, this hard drive delivers fast and reliable performance for continuous 24x7 operation.
| General | |
|---|---|
| Buffer Size | 512 MB |
| Form Factor | 3.5" |
| Weight | 720 g |
| Capacity | 16 TB |
| Device Type | Hard drive - internal |
| Interface | SAS 12Gb/s |
| Features | 24x7 availability, Conventional magnetic recording (CMR), Flux Control Microwave Assisted Magnetic Recording (FC-MAMR), Helium Sealed-Drive Design, workload up to 550 TB per year, advanced format 512e, Persistent Write Cache technology |
| Power | |
| Power Consumption | 8.71 Watt (read/write)4.49 Watt (active idle) |
| Environmental Parameters | |
| Min Operating Temperature | 5 °C |
| Max Operating Temperature | 55 °C |
| Max Storage Temperature | 70 °C |
| Min Storage Temperature | -40 °C |
| Humidity Range Operating | 5 - 90% (non-condensing) |
| Shock Tolerance (operating) | 70 g @ 2 ms |
| Shock Tolerance (non-operating) | 250 g @ 2 ms |
| Vibration Tolerance (non-operating) | 3 g @ 5-500 Hz |
| Vibration Tolerance (operating) | 0.75 g @ 5-300 Hz |
| Performance | |
| Spindle Speed | 7200 rpm |
| Drive Transfer Rate | 12 Gbit/s (external) |
| Internal Data Rate | 268 MBps |
| Reliability | |
| 24x7 Operation | Yes |
| Non-Recoverable Errors | 10 per 10^16 |
| Load / Unload Cycles | 600,000 |
| MTBF | 2,500,000 hours |
| Expansion & Connectivity | |
| Compatible Bay | 3.5" |
| Interfaces | 1 x SAS 12 Gb/s |
