Synology Disk Station DS2422+ - NAS server

DS2422+ - 4711174723980

Brand: Synology
Product code: DS2422+
SKU: 5EZEVT81KXNV7
EAN/GTIN: 4711174723980

NAS server
12 bays
SATA 3Gb/s
RAID 0, 1, 5, 6, 10, JBOD
RAM 4 GB
Gigabit Ethernet
iSCSI support
Weight: 12.62 KG

€2363.53 (Inc. VAT)

(Delivery 2-4 working days)

Product Info

The 12-bay Synology DiskStation DS2422+ is a capable choice for small and medium businesses with large storage, file sharing, and data protection requirements in a multi-user environment. It comes with powerful storage management, file syncing, surveillance, and backup software, and is suitable for editing high-quality video and as VM storage.

Description

Maximize bandwidth Handle heavier input/output and serve more users with dual-port Synology 10 or 25GbE network interface cards. Boost storage performance Accelerate HDD arrays with an M. 2 NVMe SSD adapter card and SNV3000 series SSDs, or install SAT5200 SATA SSDs in drive bays to increase performance with SSD cache. Do both with one card Add both 10GbE connectivity and M. 2 NVMe SSD slots for SSD cache with a single combination NIC and adapter card.

Specifications

General

Built-in Devices Led panel

Width 30 cm

Height 27 cm

Host Connectivity Gigabit Ethernet

Depth 34 cm

Installed Devices / Modules Qty 0 (installed) / 12 (max)

Total Storage Capacity 0 GB

Device Type NAS server

Weight 9.5 kg ()

Expansion / Connectivity

Expansion Bays 12 (total) / 12 (free) x hot-swap - 2.5" / 3.5"

Expansion Slots 1 (total) / 1 (free) x PCI Express 3.0 x82 (total) / 1 (free) x SO-DIMM 260-pin

Interfaces 2 x USB 3.2 Gen 1 - Type A4 x Ethernet 1000Base-T - RJ-451 x expansion port

Manufacturer Warranty

Service & Support Limited warranty - 3 years

Networking

Compliant Standards DLNA CERTIFIED

Remote Management Protocol SNMP, Telnet, HTTP, HTTPS, SSH

Network / Transport Protocol TCP/IP, AppleTalk, LPR/LPD, FTP

Network Services Compatibility Microsoft Active Directory (AD), DDNS, Microsoft CIFS, Network File System (NFS), FTP, Apple File Protocol (AFP)

Data Link Protocol 10Mb LAN, 100Mb LAN, 1GbE

Features Firewall protection, E-mail alert, print server, firmware upgradable, MySQL server, web server, backup server, file sharing, ADS, SSH support, iTunes server, Samba support, FTP server, SMS alert, BitTorrent Client, e-mail server

Miscellaneous

Included Accessories Accessory pack

Features Built-in 2 cooling fans, lockable, wake on LAN, reset button, scheduled power on/off

Compliant Standards RoHS, VCCI, BSMI, FCC, KC, EAC, RCM

Power

Power Provided 550 Watt

Power Device Internal power supply

Voltage Required AC 100-240 V (50/60 Hz)

Power Consumption Operational 73.11 Watt

Software / System Requirements

Storage Operating System Synology DiskStation Manager

Environmental Parameters

Max Operating Temperature 40 °C

Min Operating Temperature 5 °C

Sound Emission 25 dBA

Humidity Range Operating 5 - 95% RH

Storage Controller

Type RAID

RAID Level RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD

Interface Type SATA 3Gb/s

Processor / Memory

Max Supported Qty 1

Number of Cores Quad-Core

RAM 4 GB (installed) / 32 GB (supported) - DDR4

Processors Installed 1 x AMD Ryzen Embedded V1500B 2.2 GHz
