Eaton 5PX G2 - UPS - 1500 Watt - 1500 VA
- Brand
- Eaton
- Product code
- 5PX1500IRT2UG2BS
- SKU
- FPN4L8D9XF5AA
- EAN/GTIN
- 3553340620850
- UPS (rack-mountable / external)
- AC 150
- 294 V
- 1500 Watt
- 1500 VA
- 1-phase
- 9 Ah
- RS-232, USB, Ethernet 10/100/1000
- output connectors: 8
- 2U
- black, silver
- Weight: 28.26 KG
Product Info
The Eaton 5PX G2 is designed to provide reliable power protection and management for critical IT equipment. With a power capacity of 1500 VA and features such as Automatic Voltage Regulation (AVR) and Advance Battery Management (ABM), this UPS ensures consistent performance while prolonging battery life. It accommodates a wide input voltage range of AC 150 - 294 V, suitable for various environments. Its robust design includes a maintenance-free battery, an intuitive LCD display, and eight output connectors, ensuring efficient power distribution across devices. With a range of remote management options including SNMP and various management interfaces, the Eaton 5PX G2 offers comprehensive monitoring and control capabilities. Crafted to withstand operating temperatures from 0°C to 40°C and high humidity up to 90% (non-condensing), this UPS is built to handle demanding conditions. Compliant with ENERGY STAR and multiple safety standards, it delivers peace of mind and confidence in power reliability for valuable equipment.
Description
Reliable power capacity
With a power capacity of 1500 VA, this UPS delivers consistent performance for critical IT devices while ensuring efficient energy usage.
Advanced management options
Equipped with options such as SNMP and various management interfaces, users can monitor and control power settings with ease.
Maintenance-free battery
This UPS features a lead acid battery that requires no maintenance, allowing for uninterrupted and hassle-free power supply.
Flexible connectivity options
Includes eight output connectors and a diverse range of input options to accommodate various devices and configurations.
Environmentally compliant
Complies with ENERGY STAR and multiple international safety standards, ensuring a responsible choice for power management.
| General | |
|---|---|
| Colour | Black, silver |
| Height (Rack Units) | 2U |
| Device Type | UPS - rack-mountable / external |
| Expansion / Connectivity | |
| Expansion Slots | 1 (total) / 0 (free) x Expansion Slot |
| Interfaces | 1 x management (RS-232) - RJ-451 x management (USB) - 4 pin USB Type B1 x management (Gigabit Ethernet) - RJ-45Remote power (on/off) - mini terminal blockRelay output - mini terminal block |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - electrical components and functions - 3 yearsLimited warranty - batteries - 2 years |
| Networking | |
| Remote Management Protocol | SNMP |
| Remote Management Interface | RS-232, USB, Ethernet 10/100/1000 |
| Miscellaneous | |
| Rack Mounting Kit | Included |
| Included Accessories | Tower stand |
| Cables Included | 2 x power cable (IEC)Power cable |
| Features | Automatic Voltage Regulation (AVR), LCD display, Advance Battery Management (ABM) |
| Compliant Standards | CAN/CSA C22.2, CM, cTUVus, EAC, EN 62040-1, EN 62040-2, EN 62040-3, IEC 62040-1, IEC 62040-2, IEC 62040-3, REACH, RoHS, UKCA, UL 1778 |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 0 - 90% (non-condensing) |
| Battery | |
| Technology | Lead Acid |
| Voltage Provided | 12 V |
| Capacity | 9 Ah |
| Features | Maintenance free |
| Quantity | 4 (supported) |
| Power Device | |
| Frequency Provided | 50/60 Hz |
| UPS Technology | Line interactive |
| Output Waveform | Sinewave |
| Input Voltage Range | AC 160 - 294 V |
| Input Voltage | AC 150 - 294 V |
| Input Voltage Range (Adjustable) | AC 150 - 294 V |
| Frequency Required | 47 - 70 Hz |
| Output Voltage | AC 200/208/220/230/240 V + 6% / - 10% - 50/60 Hz |
| Input Wiring | 1-phase |
| Power Capacity | 1500 Watt / 1500 VA |
| Input Connectors | 1 x power IEC 60320 C14 |
| Power Output Connectors Details | 8 x power IEC 60320 C13 |
| Dimensions & Weight | |
| Height | 24 cm |
| Width | 49.8 cm |
| Weight | 22.5 kg |
| Depth | 58.5 cm |
| Sustainability Information | |
| ENERGY STAR | Yes |
