Eaton 5S 1500i - UPS - 900 Watt - 1500 VA
Eaton 5S 1500i - UPS - 900 Watt - 1500 VA
- Brand
- Eaton
- Product code
- 5S1500IBS
- SKU
- NOM90QWDBUCEJ
- EAN/GTIN
- 3553340620201
- UPS
- AC 220/230/240 V
- 900 Watt
- 1500 VA
- 1-phase
- 9 Ah
- USB
- output connectors: 8
- black
- Weight: 12.26 KG
€435.49
(Inc. VAT)
(Delivery 2-4 working days)
Product Info
The compact Eaton 5S UPS delivers backup power for desktop PCs and workstations. The eco-control capability enables you save up to 30 percent in energy consumption. The 5S displays critical UPS information on battery time and outage tracking through a user-friendly LCD interface.
Description
Efficient power management
The Eaton 5S UPS features line interactive technology that provides reliable, efficient power management to protect your devices during power fluctuations.
Convenient connectivity
With a USB remote management interface, this UPS allows for easy monitoring and management of your power backup system, ensuring seamless operation and minimal downtime.
| General | |
|---|---|
| Colour | Black |
| Device Type | UPS - external |
| Expansion / Connectivity | |
| Interfaces | 1 x management (USB) - 4 pin USB Type B |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 yearsLimited warranty - batteries - 2 years |
| Networking | |
| Remote Management Interface | USB |
| Miscellaneous | |
| Features | Automatic Voltage Regulation (AVR), deep discharge protection, cold-start function, booster technology, fader technology |
| Compliant Standards | CB, IEC 62040-1, EN 62040-1, IEC/EN 62040-4 |
| Included Accessories | BS cord 10A |
| Cables Included | USB cable2 x power cable (IEC) |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 35 °C |
| Humidity Range Operating | 0 - 85% |
| Battery | |
| Quantity | 2 |
| Technology | Lead Acid |
| Voltage Provided | 12 V |
| Capacity | 9 Ah |
| Features | Sealed |
| Run Time (Up To) | 2 min at full load11 min at half load8 min at 70% load |
| Power Device | |
| Input Voltage | AC 220/230/240 V |
| UPS Technology | Line interactive |
| Power Factor (PF) | 0.6 |
| Efficiency | 97% |
| Circuit Protection | Circuit breaker |
| Frequency Required | 46 - 70 Hz |
| Power Capacity | 900 Watt / 1500 VA |
| Input Voltage Range | AC 175 - 275 V |
| Dataline Surge Protection | Network/phone line - RJ-45/RJ-11 - 1 input line / 1 output line |
| Input Wiring | 1-phase |
| Input Connectors | 1 x power IEC 60320 C14 |
| Power Output Connectors Details | 4 x power IEC 60320 C13 (surge)4 x power IEC 60320 C13 (UPS and surge) |
| Output Voltage | AC 184-276 V |
| Dimensions & Weight | |
| Weight | 12.5 kg |
| Height | 25 cm |
| Width | 8.7 cm |
| Depth | 38.2 cm |
