MiTAC B8056G68CE12HR-2T-TU - rack-mountable no CPU - SSD
- Brand
- MITAC
- Product code
- B8056G68CE12HR-2T-TU
- SKU
- 03T660W1GP6H7
- EAN/GTIN
- 635872060915
- Server
- rack-mountable 1U
- 1-way
- no CPU
- NVMe
- hot-swap 2.5" bay(s)
- SSD
- AST2600
- Gigabit Ethernet, 10 Gigabit Ethernet
- no OS
- monitor: none
- Weight: 22.42 KG
Product Info
The Mio MiTAC B8056G68CE12HR-2T-TU is designed for efficient rack-mounted server solutions. With a robust chassis that supports 12 hot-swap bays, this server utilizes NVMe technology for quick data access. It features dual PCIe 5.0 x16 expansion slots, allowing for flexibility and scalability to meet various networking and processing needs. This server operates within a temperature range of 10°C to 35°C and supports up to 24 DDR5 SDRAM slots for memory expansion. Power reliability is ensured with an 860-watt power supply and a 1+1 redundancy scheme. The advanced remote management via IPMI 2.0 and compliance with various standards further enhances its functionality, making it suitable for diverse server applications.
Description
Efficient hot-swap capability
Equipped with 12 hot-swap bays, the server allows for easy replacement of drives without powering down, ensuring minimal downtime and seamless operation.
Scalable expansion options
Features dual PCIe 5. 0 x16 slots, providing capacity for graphics cards or additional network interface cards to facilitate enhanced performance and connectivity.
Robust memory capacity
Supports up to 24 slots for DDR5 SDRAM running at 5200 MHz, allowing for substantial memory upgrades to accommodate demanding applications.
Reliable power management
Includes an 860-watt power supply with redundancy, ensuring consistent power delivery and minimizing the risk of server downtime.
Advanced remote management
Incorporates IPMI 2. 0 for effective remote management, enabling monitoring and control of server functions to enhance administration efficiency.
| General | |
|---|---|
| Type | Server |
| Internal Bays Qty | 12 |
| Front Accessible Bays Qty | 12 |
| Hot-Swap Bays Qty | 12 |
| Server Scalability | 1-way |
| Product Form Factor | Rack-mountable - 1U |
| Built-in Devices | 6 x fans |
| Expansion / Connectivity | |
| Slots | 2 PCIe 5.0 x161 PCIe 5.0 x16 / Open Compute Project mezzanine (OCP) 3.0 |
| Interfaces | 1 x USB 3.2 Gen 1 - Type A1 x USB 3.2 Gen 1COM3 x LAN (10Gigabit Ethernet) - RJ-451 x USB 3.2 Gen 12 x USB 3.2 Gen 1 |
| RAM | |
| Slots | 24 (Total) / 24 (empty) |
| Technology | DDR5 SDRAM |
| Effective Memory Speed | 5200 MHz |
| Rated Memory Speed | 5200 MHz |
| Installed Size | 6144 GB (max) |
| Networking | |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet |
| Remote Management Protocol | IPMI 2.0 |
| Ethernet Ports | 3 x Gigabit Ethernet |
| Remote Management Controller | Aspeed AST2600 |
| Ethernet Controller | Intel X710-AT2, Realtek RTL8211F |
| Miscellaneous | |
| Compliant Standards | FCC SDOC Class A, DOC-A, CB, LVD, VCCI, BSMI, RoHS, C-Tick |
| Power | |
| Device Type | Power supply |
| Power Redundancy | Yes |
| Power Provided | 860 Watt |
| Power Redundancy Scheme | 1+1 |
| 80 PLUS Certification | 80 PLUS Titanium |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Environmental Parameters | |
| Min Operating Temperature | 10 °C |
| Max Operating Temperature | 35 °C |
| Humidity Range Operating | 0 - 90% (non-condensing) |
| Optical Storage | |
| Type | No optical drive |
| Operating System / Software | |
| OS Provided | No operating system |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Video Interfaces | VGA |
| Graphics Processor | ASPEED AST2600 |
| Hard Drive | |
| Type | SSD - hot-swap |
| Interface Type | PCI Express (NVMe) |
| Dimensions & Weight | |
| Height | 4.3 cm |
| Width | 43.8 cm |
| Depth | 68 cm |
| Processor / Chipset | |
| Max CPU Qty | 1 |
| CPU Upgradability | Upgradable |
| CPU | No CPU |
| CPU Socket | Socket SP5 |
| Motherboard Name | S8056GM2NE-2T-TU |
