TP-Link Omada EAP603-Outdoor

EAP603-OUTDOOR - 1210002605748

TP-Link Omada EAP603-Outdoor 1800 Mbit/s White Power over Ethernet (PoE)

Brand: TP-Link
Product Family: Omada
Product code: EAP603-OUTDOOR
SKU: B7ZBJSDAXH5WW
EAN/GTIN: 1210002605748

Seamless 1.8Gbps Wi-Fi 6 Speeds: 574 Mbps on 2.4 GHz and 1201 Mbps on 5 GHz.†
Dual-Band Omnidirectional Coverage: Up to 300 m (984 ft) long-range coverage.*
PoE+ Powered: Supports both 802.3at PoE and Passive PoE (adapter included)
Ideal for Outdoor Environments: IP65 weatherproof, 6 kV lightning protection, and a reliable operating range of -40 °C to +70 °C
Easy and Quick Setup: Wall/pole mounting; Omada SDN for one-click setup
Advanced Features: Omada Mesh, Seamless Roaming, and Centralized Cloud Management.§

€112.68 (Inc. VAT)

Sold Out

(Delivery 2-4 working days)

1× 10M/100M/1000Mbps Gigabit Ethernet Port (RJ45), Wi-Fi 6 2.4 - 5 GHz, 300m, 230 × 207.5 × 69.7 mm

TP-Link Omada EAP603-Outdoor. 2.4 GHz, 5 GHz, Maximum data transfer rate: 1800 Mbit/s. Security algorithms: EAP, EAP-FAST, EAP-GTC, EAP-MD5, EAP-PEAP, EAP-SIM, EAP-TLS, EAP-TTLS, PEAP, PPSK, SNMP, SSH,.... Ethernet LAN data rates: 10,100,1000 Mbit/s. Power over Ethernet (PoE). Product colour: White. Power consumption (max): 4.8 W

Specifications

Features

2.4 GHz Yes

5 GHz Yes

6 GHz No

Maximum data transfer rate 1800 Mbit/s

Maximum data transfer rate (2.4 GHz) 573 Mbit/s

Maximum data transfer rate (5 GHz) 1201 Mbit/s

Ethernet LAN data rates 10,100,1000 Mbit/s

Bluetooth Yes

Maximum outdoor range 300 m

Security

Security algorithms EAP, EAP-FAST, EAP-GTC, EAP-MD5, EAP-PEAP, EAP-SIM, EAP-TLS, EAP-TTLS, PEAP, PPSK, SNMP, SSH, WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal

MAC address filtering Yes

IP address filtering Yes

Service Set Identifier (SSID) features Multiple SSIDs

Number of SSID supported 16

Guest access Yes

Remote Authentication Dial-In User Service (RADIUS) Yes

Access Control List (ACL) Yes

Management features

Web-based management Yes

Cloud-managed Yes

Backup function Yes

Ports & interfaces

Ethernet LAN (RJ-45) ports 1

Power

Power over Ethernet (PoE) Yes

Power over Ethernet (PoE) type supported Passive PoE

DC voltage range 42.5 - 57 V

Input current 0.36 A

Power consumption (max) 4.8 W

Design

Placement Pole, Wall

Product colour White

International Protection (IP) code IP65, IP66

Antenna

Antenna type Internal & external

Antenna direction type Omni-directional

Antennas quantity 4

Antenna gain level (max) 5 dBi

Certificates

Compliance certificates CE, Federal Communications Commission (FCC), RoHS

Weight & dimensions

Width 230 mm

Depth 207.5 mm

Height 69.7 mm

Packaging content

PoE adapter included Yes

Mounting kit Yes

Quick start guide Yes

Operational conditions

Operating relative humidity (H-H) 10 - 90%

Operating temperature (T-T) -30 - 70 °C

Storage temperature (T-T) -40 - 70 °C

Storage relative humidity (H-H) 5 - 90%
