MiTAC B8261T85E8HR-2T-N - rack-mountable no CPU - SSD
- Brand
- MITAC
- Product code
- B8261T85E8HR-2T-N
- SKU
- K03PYCSNT1RZL
- EAN/GTIN
- 635872057083
- Server
- rack-mountable 2U
- 2-way
- no CPU
- NVMe
- hot-swap 2.5" bay(s)
- SSD
- AST2600
- 10 Gigabit Ethernet, Gigabit Ethernet
- no OS
- monitor: none
- Weight: 37.60 KG
Product Info
The Mio MiTAC B8261T85E8HR-2T-N is a versatile rack-mountable server designed to meet the demanding needs of modern data environments. It features a robust chassis with eight internal and front-accessible hot-swap bays for easy drive management, supporting 2.5" NVMe SSDs. Built with thermal efficiency in mind, this server incorporates six hot-swap fans and two rear fans, ensuring optimal airflow and cooling under heavy loads.
Networking capabilities are advanced, boasting multiple Ethernet ports, including two 10 Gigabit Ethernet and one Gigabit Ethernet, catering to high-speed data transfer needs. The server is powered by a reliable 2700 W power supply with redundancy to maintain uptime in critical operations. Equipped with the ability to support up to two processors and ample memory slots, the Mio MiTAC B8261T85E8HR-2T-N offers scalability, ready to grow alongside your business requirements.
Description
Flexible storage options
Featuring eight hot-swap bays, this server allows for easy addition and replacement of 2. 5" NVMe SSDs, ensuring storage can be managed without downtime.
Efficient cooling system
The Mio MiTAC B8261T85E8HR-2T-N is equipped with six hot-swap fans and two rear fans, promoting effective airflow to keep internal components cool during high-performance tasks.
High-speed networking capabilities
The server includes two 10 Gigabit Ethernet ports along with one Gigabit Ethernet port, providing the bandwidth necessary for demanding applications and rapid data exchanges.
Power redundancy for reliability
A 2700 W power supply with 1+1 redundancy means that the server can continue functioning even if one power source fails, enhancing reliability.
Scalable architecture
Supporting up to two processors and 24 RAM slots allows for future upgrades, making this server suitable for growing business needs.
| General | |
|---|---|
| Type | Server |
| Internal Bays Qty | 8 |
| Front Accessible Bays Qty | 8 |
| Hot-Swap Bays Qty | 8 |
| Server Scalability | 2-way |
| Product Form Factor | Rack-mountable - 2U |
| Sensors | Temperature sensor, voltage sensor |
| Built-in Devices | 6 x hot-swap fans, 2 x rear fans |
| Expansion / Connectivity | |
| Slots | 6 PCIe 5.0 x16 |
| Interfaces | 4 x USB 3.2 Gen 1 (2 front, 2 rear)1 x VGA - DB-152 x LAN (10Gigabit Ethernet) - RJ-451 x LAN (Gigabit Ethernet) - RJ-45 |
| RAM | |
| Effective Memory Speed | 6000 MHz |
| Rated Memory Speed | 6000 MHz |
| Slots | 24 (Total) / 24 (empty) |
| Technology | DDR5 SDRAM |
| Installed Size | 6144 GB (max) |
| Networking | |
| Remote Management Protocol | IPMI 2.0 |
| Ethernet Ports | 2 x 10 Gigabit Ethernet, 1 x Gigabit Ethernet |
| Remote Management Controller | Aspeed AST2600 |
| Ethernet Controller | Intel X550-AT2, Realtek RTL8211F |
| Data Link Protocol | 10 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet |
| Miscellaneous | |
| Compliant Standards | FCC SDOC Class A, DOC-A, RoHS |
| Power | |
| Device Type | Power supply |
| Power Redundancy | Yes |
| Voltage Required | AC 100-127/200-240 V |
| Power Provided | 2700 Watt |
| Power Redundancy Scheme | 1+1 |
| 80 PLUS Certification | 80 PLUS Titanium |
| Environmental Parameters | |
| Min Operating Temperature | 10 °C |
| Max Operating Temperature | 35 °C |
| Humidity Range Operating | 90% (non-condensing) |
| Optical Storage | |
| Type | No optical drive |
| Operating System / Software | |
| OS Provided | No operating system |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Video Interfaces | VGA |
| Graphics Processor | ASPEED AST2600 |
| Hard Drive | |
| Type | SSD - hot-swap |
| Interface Type | PCI Express (NVMe) / U.2 |
| Dimensions & Weight | |
| Width | 44.8 cm |
| Height | 8.7 cm |
| Depth | 85 cm |
| Processor / Chipset | |
| Max CPU Qty | 2 |
| CPU Upgradability | Upgradable |
| CPU | No CPU |
| CPU Socket | Socket SP5 |
| Motherboard Name | Tyan S8261GM2NE-2T |
