Lenovo 4XB7A76941 internal solid state drive
Lenovo 4XB7A76941 internal solid state drive 480 GB 3.5" Serial ATA III 3D TLC NAND
- Brand
- Lenovo
- Product code
- 4XB7A76941
- SKU
- F768D86JH02OC
- 480 GB 3.5" Serial ATA III
- 79000 IOPS
- 30000 IOPS
- 3D TLC NAND
- Hardware encryption
- S.M.A.R.T. support
- Component for: Server/workstation
€1061.02
(Inc. VAT)
Sold Out
(Delivery 2-4 working days)
Product Info
The ThinkSystem S4520 Read Intensive SATA SSDs are advanced 6Gb SATA solid-state drives that use 144-layer Intel 3D NAND TLC Flash Memory technology to provide an affordable solution with industry leading performance.
This product guide provides essential presales information to understand the S4520 SSDs, their key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about S4520 SSDs and consider their use in IT solutions.
| Features | |
|---|---|
| SSD form factor | 3.5" |
| SSD capacity | 480 GB |
| Interface | Serial ATA III |
| Memory type | 3D TLC NAND |
| Component for | Server/workstation |
| Hardware encryption | Yes |
| Random read (4KB) | 79000 IOPS |
| Random write (4KB) | 30000 IOPS |
| Read latency | 36 µs |
| Write latency | 36 µs |
| S.M.A.R.T. support | Yes |
| Certification | FCC Title 47, Part 15B, Class B EN-55035:2017 EN-55022:2006 EN-55032:2012 Low Voltage Directive (LVD) 2014/35/EU EMC Directive 2014/30/EU RoHS Directive 2011/65/EU WEEE Directive 2012/19/EU UL 60950-1, 2nd Edition, 2014-10-14 CSA C22.2 No. 60950-1-07, 2nd Edition, 2014-010 UL/CSA 62368-1, 2nd Edition AS/NZ CISPR 32:2015 AS/NZ CISPR 22:2009 +A1:2010 Taiwan BSMI EMC standard CNS 13438 Korea KCC Article 11.1 Morocco Decree # 2574-14 (EMC) Canada ICES-003 Japan VCCI China EFUP |
| Power | |
| Power consumption (max) | 3 W |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 70 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating vibration | 2.17 G |
| Non-operating vibration | 3.13 G |
| Operating shock | 1000 G |
| Non-operating shock | 1000 G |
| Weight & dimensions | |
| Width | 257 mm |
| Depth | 193 mm |
| Height | 95 mm |
| Weight | 484 g |
| Logistics data | |
| Harmonized System (HS) code | 84717070 |
