Lenovo 4XB7A13642 internal solid state drive

4XB7A13642 - 5715063285251

Lenovo 4XB7A13642 internal solid state drive 1.92 TB 3.5 inch Serial ATA III 3D TLC NAND

Brand: Lenovo
Product code: 4XB7A13642
SKU: VKFD937R4NGSC
EAN/GTIN: 5715063285251

1.92 TB 3.5" Serial ATA III
96000 IOPS
42000 IOPS
3D TLC NAND
S.M.A.R.T. support
Component for: Server/workstation

€4070.39 (Inc. VAT)

Sold Out

(Delivery 2-4 working days)

Product Info

ThinkSystem 3.5" Intel S4610 1.92TB Mainstream SATA 6Gb Hot Swap

Lenovo 4XB7A13642. SSD capacity: 1.92 TB, SSD form factor: 3.5", Data transfer rate: 6 Gbit/s, Component for: Server/workstation

The Intel S4610 Mainstream SATA solid-state drives (SSDs) for Lenovo servers are advanced data center SSDs optimized for mixed read-write performance, endurance and strong data protection. The drives are available in either 2.5-inch or 3.5-inch drive form factor.

This product guide provides essential presales information to understand the S4610 SSD offerings and their key features, specifications, and compatibility. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about S4610 SSDs and consider their use in IT solutions.

Specifications

Features

SSD form factor 3.5"

SSD capacity 1.92 TB

Interface Serial ATA III

Memory type 3D TLC NAND

NVMe No

Component for Server/workstation

Data transfer rate 6 Gbit/s

Random read (4KB) 96000 IOPS

Random write (4KB) 42000 IOPS

Random latency - read (up to) 103 µs

Random latency - write (up to) 54 µs

Read latency 36 µs

Write latency 37 µs

S.M.A.R.T. support Yes

Hot-swap Yes

Uncorrectable Bit Error Rate (UBER) < 1 per 10^17 bits read

Mean time between failures (MTBF) 2000000 h

Certification FCC Title 47, Part 15B, Class B CA/CSA-CEI/IEC CISPR 22:02 EN 55024: 1998 EN 55022: 2006 EN-60950-1 2nd Edition UL/CSA EN-60950-1 2nd Edition Low Voltage Directive 2006/95/EC C-Tick: AS/NZS3584 BSMI: CNS 13438 KCC Article 11.1 RoHS DIRECTIVE 2011/65/EU WEEE Directive 2002/96/EC

Operational conditions

Operating temperature (T-T) 0 - 70 °C

Storage temperature (T-T) -55 - 95 °C

Operating relative humidity (H-H) 5 - 95%

Operating vibration 2.17 G

Non-operating vibration 3.13 G

Operating shock 1000 G

Maximum operating altitude 3050 m

Weight & dimensions

Width 257 mm

Depth 193 mm

Height 95 mm

Weight 484 g

Other features

Endurance rating 10.5 PB
