Lenovo 4XB7A82636 internal solid state drive

4XB7A82636 - 889488634743

Lenovo 4XB7A82636 internal solid state drive 480 GB M.2 PCI Express 4.0 NVMe 3D TLC NAND

Brand: Lenovo
Product code: 4XB7A82636
SKU: WMZLZYMPP72U3
EAN/GTIN: 889488634743

480 GB M.2 PCI Express 4.0
280000 IOPS
40000 IOPS
3D TLC NAND NVMe
Hardware encryption
S.M.A.R.T. support ECC
Component for: Server/workstation

€2526.24 (Inc. VAT)

Sold Out

(Delivery 2-4 working days)

Product Info

ThinkSystem M.2 7450 PRO 480GB Read Intensive NVMe PCIe 4.0 x4 NHS SSD

Lenovo 4XB7A82636. SSD capacity: 480 GB, SSD form factor: M.2, Component for: Server/workstation

The ThinkSystem 7450 PRO Read Intensive NVMe SSDs are general-purpose yet high-performance family of NVMe solid-state drives. They are engineered for greater performance and endurance in a cost-effective design, and to support a broader set of workloads. Now with SED encryption as standard, these drives help ensure data security, even when the drive is removed from the server.

This product guide provides essential presales information to understand the ThinkSystem 7450 PRO Read Intensive NVMe SSDs offerings and their key features, specifications, and compatibility. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the 7450 PRO SSDs and consider their use in IT solutions.

Specifications

Features

SSD form factor M.2

SSD capacity 480 GB

Interface PCI Express 4.0

Memory type 3D TLC NAND

NVMe Yes

Component for Server/workstation

Hardware encryption Yes

Random read (4KB) 280000 IOPS

Random write (4KB) 40000 IOPS

Read latency 80 µs

Write latency 30 µs

M.2 SSD size 2280 (22 x 80 mm)

S.M.A.R.T. support Yes

ECC Yes

Hot-swap Yes

Mean time between failures (MTBF) 2000000 h

Certification CE (Europe): EN55032, EN55024 Class B, RoHS FCC: CFR Title 47, Part 15, Class B UL/cUL: approval to UL-60950-1, 2nd Edition, IEC 60950-1:2005 (2nd Edition); EN 60950-1 (2006) + A11:2009+ A1:2010 + A12:2011 + A2:2013 BSMI (Taiwan): approval to CNS 13438, Class B, CNS 15663 RCM (Australia, New Zealand): AS/NZS CISPR32 Class B KC RRL (Korea): approval to KN32 Class B, KN 35 Class B W.E.E.E.: Compliance with EU WEEE directive 2012/19/EC. TUV (Germany): approval to IEC60950/EN60950 VCCI (Japan): 2015-04 Class B IC (Canada): ICES-003 Class B Morocco: EN55032, EN55024 Class B UkrSEPRO (Ukraine): EN55032 Class B, IEC60950/EN60950, RoHS (Resolution 2017 No. 139) UKCA (UK): SI 2016/1091 Class B and SI 2012/3032 RoHS

Power

Power consumption (read) 7 W

Power consumption (write) 4.5 W

Operational conditions

Operating temperature (T-T) 0 - 70 °C

Storage temperature (T-T) -40 - 85 °C

Operating relative humidity (H-H) 5 - 95%

Non-operating vibration 20 G

Operating shock 1500 G

Maximum operating altitude 3050 m
