Lenovo Xeon Intel Gold 6240R processor 2.4 GHz 35.75 MB
- Brand
- Lenovo
- Product Family
- Xeon
- Product code
- 4XG7A63286
- SKU
- 56K08Y1PU0RII
- EAN/GTIN
- 889488519880
- Intel® Xeon® Gold 6240R 2.4 GHz
- 35.75 MB LGA 3647 (Socket P)
- Processor cores: 24 14 nm 64-bit 165 W
- Maximum internal memory supported by processor: 1.02 TB DDR4-SDRAM
Product Info
The Intel Xeon® 6240R 2.4GHz Twenty Four Core Processor enhances the performance and the speed of your system. Additionally, the Virtualization Technology enables migration of more environments. It supports enhanced SpeedStep® technology that allows tradeoffs to be made between performance and power consumption.
Its Thermal Monitoring Technologies protect the processor package and the system from thermal failure through several thermal management features. The VT-x with Extended Page Tables (EPT) also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Packed with more features, the Xeon 6240R 2.4GHz Twenty Four Core Processor is the ideal choice for virtually all of your data demanding or standard enterprise infrastructure applications.
| Processor | |
|---|---|
| Processor manufacturer | Intel |
| Processor generation | 2nd Generation Intel® Xeon® Scalable |
| Processor model | 6240R |
| Processor base frequency | 2.4 GHz |
| Processor family | Intel® Xeon® Gold |
| Processor cores | 24 |
| Processor socket | LGA 3647 (Socket P) |
| Component for | Server/workstation |
| Processor lithography | 14 nm |
| Processor threads | 48 |
| Processor operating modes | 64-bit |
| Processor boost frequency | 4 GHz |
| Processor cache | 35.75 MB |
| Thermal Design Power (TDP) | 165 W |
| Processor codename | Cascade Lake |
| Processor ARK ID | 199343 |
| Memory | |
| Maximum internal memory supported by processor | 1.02 TB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 2933 MHz |
| Memory channels | Hexa-channel |
| ECC | Yes |
| Graphics | |
| On-board graphics card | No |
| Discrete graphics card | No |
| On-board graphics card model | Not available |
| Discrete graphics card model | Not available |
| Features | |
| Execute Disable Bit | Yes |
| Market segment | Server |
| Maximum number of PCI Express lanes | 48 |
| PCI Express slots version | 3.0 |
| Supported instruction sets | SSE4.2, AVX, AVX 2.0, AVX-512 |
| Scalability | 2S |
| Embedded options available | No |
| PCI Express CEM revision | 3.0 |
| Processor special features | |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® Speed Shift Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Turbo Boost Max Technology 3.0 | No |
| AVX-512 Fused Multiply-Add (FMA) units | 2 |
| Intel® Deep Learning Boost (Intel® DL Boost) | Yes |
| Intel® Speed Select technology - Performance Profile (Intel® SST-PP) | No |
| Intel® Volume Management Device (VMD) | Yes |
| Intel® Optane™ DC Persistent Memory Supported | Yes |
| Intel® vPro™ Platform Eligibility | Yes |
| Intel® Speed Select Technology - Base Frequency (Intel® SST-BF) | No |
| Operational conditions | |
| Tcase | 90 °C |
| Logistics data | |
| Harmonized System (HS) code | 8542310001 |
| Packaging data | |
| Package width | 43 mm |
| Package depth | 137 mm |
| Package height | 112 mm |
| Weight & dimensions | |
| Processor package size | 76.0 x 56.5 mm |
