APC Easy 3S uninterruptible power supply (UPS)

E3SUPS30KH - 0731304339564

APC Easy 3S uninterruptible power supply (UPS) Double-conversion (Online) 30 kVA 30000 W

Brand: APC HW
Product code: E3SUPS30KH
SKU: SPBTSKSC0S1SG
EAN/GTIN: 0731304339564

Double-conversion (Online)
30 kVA 30000 W
Waveform: Pure sine
Tower White

€7073.17 (Inc. VAT)

Sold Out

(Delivery 2-4 working days)

APC Easy 3S. UPS topology: Double-conversion (Online), Output power capacity: 30 kVA, Output power: 30000 W. Form factor: Tower, Product colour: White, Display type: LED. Compliance certificates: RoHS, Certification: CE, EAC, IEC 62040-1-1, IEC 62040-2, IEC 62040-3, IEC 62040-4, ISTA 2B, RCM, WEEE, REACH. Width: 250 mm, Depth: 800 mm, Height: 770 mm. Package width: 400 mm, Package depth: 982 mm, Package height: 1015 mm

Specifications

Features

UPS topology Double-conversion (Online)

Output power capacity 30 kVA

Output power 30000 W

Waveform Pure sine

Input operation voltage (min) 304 V

Input operation voltage (max) 477 V

Input frequency 45/65 Hz

Output operation voltage (min) 380 V

Output operation voltage (max) 415 V

Output frequency 50/60 Hz

Maximum current 55 A

Number of input phases 3

Number of output phases 3

Input power factor 0.99

Crest factor 3:1

Output voltage Total Harmonic Distortion (THD) 3%

Input current Total Harmonic Distortion (THD) 3%

Noise level 63 dB

Design

Form factor Tower

Product colour White

Display type LED

International Protection (IP) code IP20

Certification CE, EAC, IEC 62040-1-1, IEC 62040-2, IEC 62040-3, IEC 62040-4, ISTA 2B, RCM, WEEE, REACH

Operational conditions

Operating temperature (T-T) 0 - 40 °C

Storage temperature (T-T) -15 - 40 °C

Operating relative humidity (H-H) 0 - 95%

Storage relative humidity (H-H) 0 - 95%

Operating altitude 0 - 984.4 m

Non-operating altitude 0 - 14763.6 m

Technical details

Sustainability certificates RoHS

Weight & dimensions

Width 250 mm

Depth 800 mm

Height 770 mm

Weight 60 kg

Package width 400 mm

Package depth 982 mm

Package height 1015 mm

Package weight 77 kg

Packaging data

Quick installation guide Yes

Logistics data

Harmonized System (HS) code 85078000

Other features

Output voltage 400 V
