APC SRVPM6KRIL uninterruptible power supply (UPS)
APC Easy UPS On-Line, 6kVA/6kW, Rackmount 2U, 230V, 1x Hard wire 3-wire(1P+N+E) outlet, Intelligent Slot, Extended runtime, No battery, W/O rail kit
- Brand
- APC HW
- Product code
- SRVPM6KRIL
- SKU
- LDV81GHN3AQ4X
- EAN/GTIN
- 5054444434261
- USB connection: Use your PC to access additional power protection and management features for your UPS via a USB Port
- Allows the user to manage the UPS functions, schedule automatic shutdown and monitor the power grid occurrences through an interactive interface that ensures an easy and intuitive monitoring
- Safety-agency approved: Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment
- Pure sine wave output on battery: Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics
€2877.14
(Inc. VAT)
Sold Out
(Delivery 2-4 working days)
Product Info
APC Easy UPS On-Line SRV RM Extended Runtime 6000VA 230V No Battery
APC Easy UPS On-Line, 6kVA/6kW, Rackmount 2U, 230V, 1x Hard wire 3-wire(1P+N+E) outlet, Intelligent Slot, Extended runtime, No battery, W/O rail kit. UPS topology: Double-conversion (Online), Output power capacity: 6 kVA, Output power: 6000 W. AC outlet types: Hard Wire 3-wire (1P + N + E), Power plug: Terminal, USB port type: USB Type-B. Battery technology: Sealed Lead Acid (VRLA), Battery recharge time: 3 h. Form factor: Rackmount, Product colour: Black, Rack capacity: 2U. Compliance certificates: RoHS, Certification: CE, IEC 62040-1-1, IEC 62040-1-2 REACH
APC Easy UPS On-Line SRV RM Extended Runtime 6000VA 230V No Battery
High quality, Double-conversion On-line UPS designed for essential power protection needs even in the most unstable power conditionsHigh quality, Double-conversion On-line UPS designed for essential power protection needs even in the most unstable power conditions.
Includes: CD with software, USB cable, User Manual.
Automatic internal bypass: Supplies utility power to the connected loads in the event of a UPS power overload or fault.
Automatic restart of loads after UPS shutdown: Automatically starts up the connected equipment upon the return of utility power.
ECO Mode: Operating mode that by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection
EPO: Attach the device to an Emergency Power Off (EPO) system so that power can be turned off in an emergency situation.
Input power factor correction: Minimizes installation costs by enabling the use of smaller generators and cabling.
Intelligent battery management: Maximizes battery performance, life, and reliability through intelligent, precision charging.
LCD graphics display: Text and mimic diagrams that display modes of operation, system parameters and alarms.
Serial connectivity: Provides management of the UPS via a serial port.
USB connectivity: Provides management of the UPS via a USB port (not available on all models).
| Features | |
|---|---|
| UPS topology | Double-conversion (Online) |
| Output power capacity | 6 kVA |
| Output power | 6000 W |
| Waveform | Pure sine |
| Input frequency | 40/70 Hz |
| Output operation voltage (min) | 220 V |
| Output operation voltage (max) | 240 V |
| Surge energy rating | 600 J |
| Crest factor | 3:1 |
| ECO mode | Yes |
| Emergency Power Off (EPO) | Yes |
| Audible alarm(s) | Yes |
| Audible alarm modes | Alarm when on battery, Low battery alarm, Overload alarm |
| Auto-restart | Yes |
| Maintenance-free | Yes |
| Ports & interfaces | |
| Power plug | Terminal |
| USB port | Yes |
| USB 2.0 ports quantity | 1 |
| USB port type | USB Type-B |
| Serial interface | Yes |
| Serial ports quantity | 1 |
| Emergency Power Off (EPO) connector | Yes |
| SmartSlot | Yes |
| Battery | |
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery recharge time | 3 h |
| Automatic battery test | Yes |
| Design | |
| Form factor | Rackmount |
| Rack capacity | 2U |
| Product colour | Black |
| Display type | LCD |
| LED indicators | Yes |
| Certification | CE, IEC 62040-1-1, IEC 62040-1-2 REACH |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 14763.6 m |
| Technical details | |
| Sustainability certificates | RoHS |
| Weight & dimensions | |
| Width | 438 mm |
| Depth | 615 mm |
| Height | 87 mm |
| Weight | 14 kg |
| Package width | 600 mm |
| Package depth | 760 mm |
| Package height | 240 mm |
| Package weight | 18 kg |
| Packaging data | |
| Cables included | USB cable |
| Manual | Yes |
| Software CD | Yes |
| Logistics data | |
| Harmonized System (HS) code | 85078000 |
| Other features | |
| Nominal output voltage | 230 V |
| Nominal input voltage | 230 V |
