APC Smart-UPS RT 2200VA uninterruptible power supply (UPS)

SURTD2200XLIM - 731304286929

APC Smart-UPS RT 2200VA 230V - Marine

Brand: APC HW
Product code: SURTD2200XLIM
SKU: QYLDXDYC16H3W
EAN/GTIN: 731304286929

2.2 kVA 1540 W
10 AC outlet(s)
Sealed Lead Acid (VRLA)
Rackmount Black

€2626.18 (Inc. VAT)

(Delivery 2-4 working days)

Product Info

Smart-UPS RT 2200VA 230V - Marine

APC Smart-UPS RT 2200VA 230V - Marine. Output power capacity: 2.2 kVA, Output power: 1540 W, Input operation voltage (min): 100 V. AC outlet types: C13 coupler, C19 coupler, AC outlets quantity: 10 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery recharge time: 2.5 h. Form factor: Rackmount, Product colour: Black, Rack capacity: 3U. Compliance certificates: RoHS, Certification: CE, DNV, EN 50091-1, EN 50091-2, EN 55022 Cl. A, EN 60950, EN 61000-3-2.

APC Smart-UPS On-Line, 1540 Watts / 2200 VA, Input 230V / Output 230V , Interface Port RJ-45 Serial, Smart-Slot , Extended runtime model , Rack Height 3 U

Includes: CD with software, Documentation CD, Installation guide, Rack mounting hardware, Smart UPS signalling RS-232 cable, User Manual

Standard Lead Time: Usually in Stock

Specifications

Features

Output power capacity 2.2 kVA

Output power 1540 W

Input operation voltage (min) 100 V

Input operation voltage (max) 280 V

Input frequency 50/60 Hz

Output operation voltage (min) 220 V

Output operation voltage (max) 240 V

Surge energy rating 480 J

Efficiency 92%

Crest factor 3:1

Emergency Power Off (EPO) Yes

Output voltage Total Harmonic Distortion (THD) 3%

Noise level 55 dB

Audible alarm(s) Yes

Ports & interfaces

AC outlet types C13 coupler, C19 coupler

AC outlets quantity 10 AC outlet(s)

Number of output IEC jumpers 2

Ethernet LAN (RJ-45) ports 1

Battery

Battery technology Sealed Lead Acid (VRLA)

Battery recharge time 2.5 h

Design

Form factor Rackmount

Rack capacity 3U

Cable length 2.5 m

Product colour Black

Certification CE, DNV, EN 50091-1, EN 50091-2, EN 55022 Cl. A, EN 60950, EN 61000-3-2.

Operational conditions

Operating temperature (T-T) 0 - 55 °C

Storage temperature (T-T) -15 - 45 °C

Operating relative humidity (H-H) 0 - 95%

Storage relative humidity (H-H) 0 - 95%

Operating altitude 0 - 3000 m

Non-operating altitude 0 - 15000 m

Technical details

Sustainability certificates RoHS

Weight & dimensions

Width 130 mm

Depth 660 mm

Height 432 mm

Weight 54.5 kg

Package weight 63.6 kg

Logistics data

Harmonized System (HS) code 85078000

Other features

Dimensions (WxDxH) 130 x 660 x 432 mm

Nominal output voltage 230 V

Nominal input voltage 230 V

Package dimensions (WxDxH) 603 x 980 x 347 mm
