D-Link DGS-3420-52T network switch

Management features

Switch type Managed

Switch layer L2

Quality of Service (QoS) support Yes

Web-based management Yes

MIB support Y

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity 48

SFP/SFP+ slots quantity 4

SFP+ module slots quantity 4

Network

Networking standards IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x

Copper ethernet cabling technology 1000BASE-T, 100BASE-T, 10BASE-T

Port mirroring Yes

Flow control support Yes

Link aggregation Yes

Spanning tree protocol Yes

Data transmission

Supported data transfer rates 10/100/1000 Mbps

Switching capacity 176 Gbit/s

MAC address table 16000 entries

Maximum data transfer rate 1 Gbit/s

Jumbo frames support Yes

Packet buffer memory 2 MB

Security

DHCP features DHCP server, DHCP client

Access Control List (ACL) Yes

IGMP snooping Yes

MAC address filtering Yes

Protocols

Management protocols SNMP

Supported network protocols IPv4/IPv6

Design

Rack mounting Yes

Stackable Yes

Product colour Black

LED indicators Yes

Safety CB, cUL, LVD

Performance

Noise level 51.1 dB

Mean time between failures (MTBF) 255608 h

Technical details

Shipping (inner) case height 60.3 cm

Shipping (inner) case width 33.6 cm

Shipping (inner) case length 55 cm

Shipping (inner) case net weight 11.6 kg

Products per shipping (inner) case 2 pc(s)

Pallet gross weight (air) 331.7 kg

Master (outer) cases per pallet (air) 18 pc(s)

Products per pallet (air) 36 pc(s)

Pallet gross length 110 cm

Pallet gross width 120 cm

Pallet height (air) 194.4 cm

Pallet gross weight (sea) 331.7 kg

Master (outer) cases per pallet (sea) 18 pc(s)

Products per pallet (sea) 36 pc(s)

Pallet height (sea) 194.4 cm

Shipping (inner) case gross weight 17.4 kg

Power

Power source AC

Power consumption (typical) 81 W

Power over Ethernet (PoE)

Power over Ethernet (PoE) No

Operational conditions

Operating temperature (T-T) 0 - 50 °C

Storage temperature (T-T) -40 - 70 °C

Operating relative humidity (H-H) 0 - 90%

Storage relative humidity (H-H) 5 - 90%

Heat dissipation 276.2 BTU/h

Weight & dimensions

Weight 5.07 kg

Packaging data

Package width 530 mm

Package depth 568 mm

Package height 157 mm

Package weight 7.95 kg

Logistics data

Harmonized System (HS) code 85176990

Other features

Management platform CLI

Data transfer rate 1000 Mbit/s

Dimensions (WxDxH) 441 x 310 x 44 mm

Connectivity technology Wired

Packet transfer speed 130.95

Networking features Gigabit Ethernet
