D-Link DES-1016D

D-Link 16-Port Fast Ethernet Unmanaged Desktop Switch


Brand
D-Link
Product code
DES-1016D/B
SKU
53HVQMQY6BJPF
EAN/GTIN
790069221262
  • Unmanaged
  • Quality of Service (QoS) support
  • Basic switching RJ-45 Ethernet ports quantity: 16
  • 100BASE-TX, 10BASE-T
  • MAC address table: 8000 entries Switching capacity: 3.2 Gbit/s
€56.33 (Inc. VAT)
(Delivery 2-4 working days)

Product Info

The DES-1016D 16-Port Fast Ethernet Unmanaged Desktop Switch is designed to enhance workgroup performance while providing a high level of flexibility. Powerful yet easy to use, this device allows users to simply plug any port to either a 10Mbps or 100Mbps network to multiply bandwidths, boost response time and satisfy heavy load demands.

Ideal for Basic Networking Tasks
With the D-Link DES-1016D, you can easily expand your network by adding more computers or devices with speeds up to 200 Mbps per port in full-duplex mode.

Auto-Sensing 10/100 Ports
The DES-1016D use auto-sensing 10/100 Mbps ports, allowing a small workgroup to flexibly connect to 10 or 100 Mbps devices to create an integrated network. Each port automatically adjusts for straight-through or crossover cables to make the right link.

Flow Control for Secure Transmission
802.3x flow control on each port minimizes dropped packets when the port’s receiving buffer is full.

Quality of Service (QoS)
The switches provide 802.1p priority queues for QoS, allowing users to run bandwidth-sensitive applications such as multimedia and VoIP Internet telephone without data flow bottlenecks that can degrade the quality of the network connection.

Save on Energy Costs
The switches support IEEE802.3az EEE which enables the switches to reduce power consumption when the switches are at low utilization, allowing users to save on power usage and costs. During these periods of low utilization, the switches can enter a low-power state and use up less power than regular operations.

Management features
Switch type Unmanaged
Quality of Service (QoS) support Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity 16
Basic switching RJ-45 Ethernet ports type Fast Ethernet (10/100)
Network
Networking standards IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
10G support No
Copper ethernet cabling technology 100BASE-TX, 10BASE-T
Full duplex Yes
Flow control support Yes
Auto MDI/MDI-X Yes
Auto-sensing Yes
Data transmission
Switching capacity 3.2 Gbit/s
MAC address table 8000 entries
Store-and-forward Yes
Maximum data transfer rate 0.2 Gbit/s
Protocols
Supported network protocols CSMA/CD
Design
Rack mounting No
Stackable No
Product colour Black
LED indicators Activity, Link, Power, Power
Certification FCC Class A, ICES-003 Class A, CE Class A, C-Tick Class A, VCCI Class A, LVD, cUL
Performance
Internal memory 2 MB
Mean time between failures (MTBF) 2266559 h
Technical details
Shipping (inner) case height 31.1 cm
Shipping (inner) case width 39.2 cm
Shipping (inner) case length 42 cm
Shipping (inner) case net weight 9 kg
Products per shipping (inner) case 5 pc(s)
Pallet gross weight (air) 253.9 kg
Master (outer) cases per pallet (air) 24 pc(s)
Products per pallet (air) 120 pc(s)
Pallet gross length 120 cm
Pallet gross width 110 cm
Pallet height (air) 137.9 cm
Pallet gross weight (sea) 372.3 kg
Master (outer) cases per pallet (sea) 36 pc(s)
Products per pallet (sea) 180 pc(s)
Pallet height (sea) 2 m
Shipping (inner) case gross weight 9.87 kg
Power
AC input voltage 100 - 240 V
AC input frequency 50 - 60 Hz
Power consumption (typical) 2.89 W
Power over Ethernet (PoE)
Power over Ethernet (PoE) No
Operational conditions
Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -10 - 70 °C
Operating relative humidity (H-H) 10 - 90%
Storage relative humidity (H-H) 5 - 90%
Heat dissipation 9.86 BTU/h
Weight & dimensions
Width 280 mm
Depth 125.8 mm
Height 44 mm
Packaging data
Package width 282 mm
Package depth 376 mm
Package height 78 mm
Package weight 1.8 kg
Logistics data
Harmonized System (HS) code 85176990
We do not guarantee the completeness and accuracy of the product details, which are obtained from outside sources.
