D-Link DES-1008D Unmanaged Fast Ethernet (10/100) Black
- Brand
- D-Link
- Product code
- DES-1008D/E
- SKU
- MFUW2J7ECKJ08
- Unmanaged
- Basic switching RJ-45 Ethernet ports quantity: 8
- 100BASE-TX, 10BASE-T
- MAC address table: 1024 entries Switching capacity: 1 Gbit/s
Product Info
8 10/100Mbps Ports - Unmanaged Stand-alone - Layer 2 Switch: This compact palm-sized switch is designed for the home and small offices. It provides 8 10/100Mbps ports to connect to 8 workstations and servers. Hubs can also connect to this switch.
All ports auto-sense the network speed of the computers and hubs to run at either 10Mbps or 100Mbps. The ports also auto-negotiate between full and half duplex and support flow control. Expansion is easy through a MDI uplink port. You cascade several switches together through this port to get more ports.
IEEE 802.3x Flow Control allows your servers to directly connect to this switch for fast, reliable data transfer. At 200Mbps full duplex, this switch provides high-speed data pipes to your Servers with minimum data transfer loss.
Auto-negotiation of MDI/MDIX cross over eliminates the need for cross over cables or uplink ports. Any port can simply plug to a server, workstation, a hub or another switch using the usual straight-through twisted-pair cable.
| Management features | |
|---|---|
| Switch type | Unmanaged |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
| Power connector | DC-in jack |
| Network | |
| Networking standards | IEEE 802.3, IEEE 802.3x |
| 10G support | No |
| Copper ethernet cabling technology | 100BASE-TX, 10BASE-T |
| Full duplex | Yes |
| Flow control support | Yes |
| Auto MDI/MDI-X | Yes |
| Data transmission | |
| Switching capacity | 1 Gbit/s |
| MAC address table | 1024 entries |
| Design | |
| Rack mounting | No |
| Stackable | No |
| Product colour | Black |
| LED indicators | Yes |
| Performance | |
| Maximum data transfer rate | 100 Mbit/s |
| Mean time between failures (MTBF) | 116186 h |
| Technical details | |
| Shipping (inner) case height | 35 cm |
| Shipping (inner) case width | 21.1 cm |
| Shipping (inner) case length | 54.3 cm |
| Shipping (inner) case net weight | 3.96 kg |
| Products per shipping (inner) case | 20 pc(s) |
| Pallet gross weight (air) | 330.5 kg |
| Master (outer) cases per pallet (air) | 50 pc(s) |
| Products per pallet (air) | 1000 pc(s) |
| Pallet gross length | 110 cm |
| Pallet gross width | 120 cm |
| Pallet height (air) | 188.5 cm |
| Pallet gross weight (sea) | 330.5 kg |
| Master (outer) cases per pallet (sea) | 50 pc(s) |
| Products per pallet (sea) | 1000 pc(s) |
| Pallet height (sea) | 188.5 cm |
| Shipping (inner) case gross weight | 6.23 kg |
| Power | |
| Input current | 1 A |
| Output voltage | 5 V |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | No |
| Packaging data | |
| Package width | 104 mm |
| Package depth | 158 mm |
| Package height | 94 mm |
| Package weight | 310 g |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
