• InfiniteFix Product Image

NETGEAR GS105E

GS105E-200UKS - 606449101539

NETGEAR GS105E Managed L2/L3 Gigabit Ethernet (10/100/1000) Grey


Brand
Netgear
Product code
GS105E-200UKS
SKU
5PI98KMCWWTWO
EAN/GTIN
606449101539
  • Managed L2/L3
  • Quality of Service (QoS) support
  • Basic switching RJ-45 Ethernet ports quantity: 5
  • 1000BASE-T, 100BASE-T, 10BASE-T
  • MAC address table: 8000 entries Switching capacity: 10 Gbit/s
€44.75 (Inc. VAT)
(Delivery 2-4 working days)

Product Info

GS105E - 5x RJ-45, 270 g, 10/100/1000 Mbps

NETGEAR GS105E. Switch type: Managed, Switch layer: L2/L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 5. Full duplex. MAC address table: 8000 entries, Switching capacity: 10 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3i, IEEE 802.3u, IEEE...

More Capabilities beyond Plug-and-play Connectivity
Today’s growing businesses demand and rely more on their network to carry out mission-critical business activities. Companies are putting more network traffic and applications on their Ethernet infrastructure. For example, the increasing deployments of VoIP phones and IP cameras require more than simple plug-and-play connectivity. It needs the network intelligence to separate the voice and video traffic from data, and prioritize them accordingly. Additionally, Internet-based applications such as Hotmail and Google Calendaring have made keeping the network up a business-critical need. However, companies do not necessarily have more money or advanced
training to deal with complex managed switches. The NETGEAR ProSAFE Plus Switches meet this growing need by providing fundamental network features that will help optimize the performance of business networks. ProSAFE Plus Switches also offer traffic monitoring for users to observe traffic behavior. If there are connectivity issues, these switches can identify and even locate
connection problems via cable diagnostic test. To optimize traffic through the switches, ProSAFE Plus Switches offer both port and tag-based prioritization to keep latency-sensitive traffic moving ahead of less critical packets. Also, ProSAFE Plus Switches offer port and 802.1Q-based VLAN as a means of improving security and network performance. ProSAFE Plus Switches are an upgrade from the plug-and-play Unmanaged Switch, delivering great value for empowering your network, delivering great value to the end user.

Specifications

Management features
Switch type Managed
Switch layer L2/L3
Quality of Service (QoS) support Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity 5
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Network
Networking standards IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
10G support No
Copper ethernet cabling technology 1000BASE-T, 100BASE-T, 10BASE-T
Port mirroring Yes
Full duplex Yes
Flow control support Yes
Broadcast storm control Yes
VLAN support Yes
Number of VLANs 64
Data transmission
Switching capacity 10 Gbit/s
MAC address table 8000 entries
Jumbo frames support Yes
Security
DHCP features DHCP client
IGMP snooping Yes
Multicast features
Multicast support Yes
Number of multicast groups filtered 128
Design
Rack mounting No
Stackable No
Product colour Grey
LED indicators Yes
Certification CE,CSA (CSA 22.2 #950) UL (UL 1950)/cUL IEC 950/EN 60950 FCC Part 15, VCCI, EN55022 (CISPR 22), C-Tick, EN50082-1, EN55024, CCC
Technical details
Shipping (inner) case height 28 cm
Shipping (inner) case width 49.7 cm
Shipping (inner) case length 34.4 cm
Shipping (inner) case net weight 9.92 kg
Products per shipping (inner) case 15 pc(s)
Master (outer) cases per pallet layer 6 pc(s)
Layers per pallet (air) 4 pc(s)
Layers per pallet (sea) 7 pc(s)
Power over Ethernet (PoE)
Power over Ethernet (PoE) No
Operational conditions
Operating temperature (T-T) 0 - 50 °C
Storage temperature (T-T) -20 - 70 °C
Operating relative humidity (H-H) 0 - 90%
Storage relative humidity (H-H) 0 - 95%
Operating altitude 0 - 3000 m
Weight & dimensions
Width 94 mm
Depth 101 mm
Height 26 mm
Weight 270 g
Packaging data
Quick start guide Yes
Package width 155 mm
Package depth 239 mm
Package height 63 mm
Package weight 570 g
Logistics data
Harmonized System (HS) code 85176990
