TP-Link TL-SG105

TP-Link 5-Port 10/100/1000Mbps Desktop Network Switch


Brand
TP-Link
Product code
TL-SG105
SKU
NU41PZM43N6AF
EAN/GTIN
6935364021320
  • 5 10/100/1000Mbps Auto-Negotiation RJ45 ports supporting Auto-MDI/MDIX
  • Green Ethernet technology saves the power up to 84%
  • IEEE 802.3X flow control provides reliable data transfer
  • Steel housing, desktop or wall-mounting design
  • Support 802.1p/DSCP QoS* and IGMP Snooping function
  • Plug and play ,no configuration needed
€30.64 (Inc. VAT)
(Delivery 2-4 working days)

Product Info

What This Product Does
The TP-LINK 5-Port 10/100/1000Mbps Desktop Switch provides you an easy way to make the transition to Gigabit Ethernet. Increase the speed of your network server and backbone connections, or make Gigabit to the desktop a reality. Moreover, TL-SG105 adopts lower power consumption design. With the innovative energy-efficient technology, the TL-SG105 can save up to 65% of the power consumption, making it an eco-friendly solution for your home or office network.

Gigabit Switch
Featured with 5x 10/100/1000Mbps ports, TL-SG105 greatly expands your network capacity, enabling instant large files transferring. So, power users in the home, office, workgroup, or creative production environment can now move large, bandwidth-intensive files faster. Transfer graphics, CGI, CAD, or multimedia files across the network instantly.

Go Green With Your Ethernet
You now have the choice to go green when upgrading to a gigabit network! This new generation TL-SG105 5-Port 10/100/1000Mbps Desktop Switch features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status and cable length to limit the carbon footprint of your network.
- Power down Idle Ports
When a computer or network equipment is off, the corresponding port of a traditional switch will continue to consume considerable amounts of power. The TL-SG105 can automatically detect the link status of each port and reduce the power consumption of ports that are idle, resulting in up to an 65% reduction in power use.
- Power Budget According to Cable Length
Ideally, shorter cable would use less power because of less power degradation over their length; this is not the case with most devices as they will use the same amount of power across the cable regardless of the length.

Management features
Switch type Unmanaged
Quality of Service (QoS) support Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity 5
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity 5
Power connector DC-in jack
Network
Networking standards IEEE 802.1p, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
10G support No
Full duplex Yes
Flow control support Yes
Auto MDI/MDI-X Yes
Ethernet LAN data rates 10,100,1000 Mbit/s
Auto-negotiation Yes
Data transmission
Supported data transfer rates 10/100/1000Mbps
Switching capacity 10 Gbit/s
Forwarding rate 7.4 Mpps
MAC address table 2000 entries
Store-and-forward Yes
Maximum data transfer rate 2 Gbit/s
Jumbo frames support Yes
Jumbo frames 16000
Packet buffer memory 1 MB
Security
IGMP snooping Yes
Protocols
Switching protocols CSMA/CD
Design
Product colour Black
LED indicators Yes
Certification CE, FCC, RoHS
Power
Power source DC
Power supply included Yes
Input current 0.6 A
Input voltage 9 V
Power consumption (max) 2.3 W
Power over Ethernet (PoE)
Power over Ethernet (PoE) No
Operational conditions
Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -40 - 70 °C
Operating relative humidity (H-H) 10 - 90%
Storage relative humidity (H-H) 5 - 90%
Heat dissipation 7.83 BTU/h
Weight & dimensions
Width 100 mm
Depth 98 mm
Height 25 mm
Packaging data
User guide Yes
Package type Box
Rack mount kit Yes
Package width 125 mm
Package depth 128 mm
Package height 92 mm
Package weight 370 g
Other features
Connectivity technology Wired
Wi-Fi No
Power LED Yes
Ethernet LAN Yes
