TP-Link TL-WA801N

TP-Link 300Mbps Wireless N Access Point


Brand
TP-Link
Product code
TL-WA801N
SKU
AE35FZ1H42CON
EAN/GTIN
6935364052478
  • 300 Mbps wireless speed ideal for smooth HD video, voice streaming, and online gaming
  • Supports multiple operation modes: Access Point, Multi-SSID, Client, and Range Extender modes
  • Protects your home network with WPA2 encryption and makes quick connection with the push of a button
  • Up to 30 meters (100 feet) of flexible deployment with included Passive Power over Ethernet Injector
€37.36 (Inc. VAT)
Sold Out
(Delivery 2-4 working days)

Product Info

TP-Link 300Mbps Wireless N Access Point. 2.4 GHz, Maximum data transfer rate: 300 Mbit/s. Security algorithms: WEP, WPA, WPA-PSK, WPA2, WPA2-PSK. Ethernet LAN data rates: 10,100 Mbit/s. Power over Ethernet (PoE). Product colour: White

What This Product Does
The TP-LINK Wireless N Access Point TL-WA801N is designed to establish or expand a scalable high-speed wireless N network or to connect multiple Ethernet-enabled devices such as game consoles, digital media adapters, printers, or network-attached storage devices to a wireless network. The AP supports a host of different functions that makes your wireless networking experience more flexible than ever before. Now, you can enjoy a better Internet experience when downloading, gaming, video streaming or any other applications that you may wish to use.

Wireless N - Speed & Range
Adopting IEEE 802.11n advanced MIMO (Multi Input Multi Output) technology, it simultaneously works through two antennas to Tx and Rx to overcome the interference and signal degradation when traveling long distances or through physical barriers in a small office or a large apartment, resulting in an incredible improvement in the wireless performance, even in a steel-and-concrete building. Above all, you could easily pick up the wireless network during long-distance connection where legacy 11g products may not!

Multiple Operating Modes
- Easy to Build WLAN
Supports multiple operation modes (Access Point, Multi-SSID, Client, Range Extender) to enable various wireless applications to give users a more dynamic and comprehensive experience when using their APs. Multiple operating modes also help you easily build wireless network for hard-to-wire locations or eliminating wireless dead zone.

Passive PoE Supported
- More Flexible Deployment
The TL-WA801N is able to be powered using an Ethernet cable to simultaneously send data and electricity to wherever your AP may be located even up to 100 feet away. This feature multiplies your options allowing you to place the AP in a position that is most convenient to get the best signal possible, such as on the wall or on the ceiling of your office.

Features
2.4 GHz Yes
5 GHz No
6 GHz No
Maximum data transfer rate 300 Mbit/s
Maximum data transfer rate (2.4 GHz) 300 Mbit/s
Ethernet LAN data rates 10,100 Mbit/s
Frequency band 2.4-2.4835 GHz
Networking standards IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Automatic channel selection Yes
Automatic channel scanning Yes
Wi-Fi Multimedia (WMM)/(WME) Yes
VLAN support Yes
Quality of Service (QoS) support Yes
Transmitting power (CE) 15 dBm
Transmitting power (FCC) 20 dBm
Receiver sensitivity 11g 6Mbps: -90dBm 11g 54Mbps: -77dBm 11n HT20 MC7: -73dBm 11n HT40 MC7: -70dBm
Security
Security algorithms WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Management features
Firmware upgradeable Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports 1
WAN connection Ethernet (RJ-45)
DC-in jack Yes
Power
Power over Ethernet (PoE) Yes
Power over Ethernet (PoE) type supported Passive PoE
Output voltage 9 V
Output current 0.6 A
Design
Placement Table
Product colour White
Reset button Yes
WPS push button Yes
Certification CE, FCC, RoHS
Antenna
Antenna type External
Antenna direction type Omni-directional
Antennas quantity 2
Weight & dimensions
Width 181.6 mm
Depth 129.7 mm
Height 34.7 mm
Packaging data
Package width 310 mm
Package depth 223 mm
Package height 70 mm
Package weight 560 g
Package type Box
Packaging content
Number of products included 1 pc(s)
AC adapter included Yes
PoE adapter included Yes
Cables included LAN (RJ-45)
Quick start guide Yes
Operational conditions
Operating relative humidity (H-H) 10 - 90%
Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -40 - 70 °C
Storage relative humidity (H-H) 5 - 90%
Logistics data
Harmonized System (HS) code 85176990
