Zyxel GS1100-24E

Zyxel GS1100-24E Unmanaged Gigabit Ethernet (10/100/1000) Black


Brand
Zyxel
Product code
GS1100-24E-GB0103F
SKU
WTYRJA94ZRQA5
EAN/GTIN
4718937614134
  • Unmanaged
  • Basic switching RJ-45 Ethernet ports quantity: 24
  • MAC address table: 8000 entries Switching capacity: 48 Gbit/s
  • Rack mounting
  • Power supply included
€100.82 (Inc. VAT)
(Delivery 2-4 working days)

Product Info

Zyxel GS1100-24E. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24. MAC address table: 8000 entries, Switching capacity: 48 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x,.... Wall mountable, Rack mounting

Plug and play connectivity
Simply unbox the GS1100 unmanaged switch, you can enjoy instant plug-n-play Gigabit connectivity without any additional settings required with auto-negotiation and auto MDI/MDI-X. Supporting 802.1p prioritization and jumbo frame, the switch ensures smooth voice and video traffic for your office network.

Whisper quiet operation
The GS1100 Series has fanless design that ensures silent operation in small or quiet office environments. The GS1100-10HP PoE model is specifically designed with an external power adapter that eliminates the need for an additional fan to cool down the device, making it perfect for quiet PoE deployments.

Energy saving
The GS1100 features Energy Efficient Ethernet(IEEE 802.3az) which automatically detects network traffic and adjusts power consumption dynamically. Zyxel’s green features also adjust power consumption by detecting the link status and cable length reducing business operating expenses.

Support PoE+
The GS1100-10HP supports PoE+ (IEEE 802.3at) which provides a maximum of 30W per port, delivering fully automated support for powering compatible IP phones, video surveillance cameras or wireless access points.

Flexible choices for your office
The GS1100 Series switch offers multiple options including 8-port, 16-port, and 24-port for diversified office applications.

Management features
Switch type Unmanaged
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity 24
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Network
Networking standards IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support No
Auto MDI/MDI-X Yes
Data transmission
Switching capacity 48 Gbit/s
Forwarding rate 35.7 Mpps
MAC address table 8000 entries
Jumbo frames 10000
Packet buffer memory 0.525 MB
Design
Rack mounting Yes
Product colour Black
LED indicators Yes
Wall mountable Yes
Certification LVD, BSMI, EMC Class A, CE, FCC, RCM, ICES-003, BSMI, RoHS, REACH
Performance
Fanless Yes
Mean time between failures (MTBF) 366919 h
Power
Power supply included Yes
AC input voltage 100 - 240 V
AC input frequency 50 - 60 Hz
Power consumption (max) 13 W
Power over Ethernet (PoE)
Power over Ethernet (PoE) No
Operational conditions
Operating temperature (T-T) 0 - 40 °C
Heat dissipation 43.53 BTU/h
Weight & dimensions
Width 267 mm
Depth 162 mm
Height 42 mm
Weight 1.5 kg
Packaging data
Cables included AC
Rack mount kit Yes
Logistics data
Harmonized System (HS) code 85176990
