D-Link 1-port Mini-GBIC SFP to 1000BaseSX, 550m for all - 10 Pack
- Brand
- D-Link
- Product code
- DEM-311GT/10
- SKU
- FMA5GEC8CTAWI
- EAN/GTIN
- 790069471612
- 850 nm multi-mode transceiver
- Maximum distance of up to 550 m
- Duplex LC connector
- MSA, RoHS-compliant
- Hot pluggable
Product Info
High-Speed Network Transmission for Business Environments
D-Link’s new line of Small Form-Factor Pluggables (SFPs) transceivers give you an industry-leading combination of performance and affordability. The DEM-311GT is a high-performance 850 nm multi-mode SFP transceiver supporting Gigabit speeds on multi-mode fiber for distances of up to 550 m. The unit features a metal housing to reduce EMI and to increase durability.
Hot Pluggable
All D-Link transceivers are hot pluggable. You can connect a transceiver while the system is powered on without causing any issues, and easily swap one for another without having to reboot the switch each time. This permits modules to be added or removed without interrupting the network, facilitating maintenance and greatly reducing downtime.
Multiple Applications
Applications of the DEM-300 Series fiber transceivers include distributed multi-processing, Gigabit switch cascading, high-speed I/O file transfer, bus extension application, and channel extender/data storage. This versatility is invaluable for an expanding network, and helps the infrastructure grow with the business.
Small Form Pluggable (SFP) Package
The Gigabit SFP Transceivers use the Small Form-factor Pluggable (SFP) design. They provide the necessary signal amplification for data to be transmitted to the network cable from the port, and vice versa. The SFP form factor is advantageous because it is smaller than other form factors such as Xenpak, X2, and 10G XFP, ensuring lower costs, lower power disruption, and higher port density.
| Performance | |
|---|---|
| SFP transceiver type | Fiber optic |
| Maximum data transfer rate | 1000 Mbit/s |
| Interface type | SFP |
| Multi-mode fiber (MMF) supported | Yes |
| Fiber optic connector | LC |
| Fiber cable diameters supported (core/cladding) | 50/125,62.5/125 µm |
| Maximum transfer distance | 550 m |
| Wavelength | 850 nm |
| Tx power (min) | -4 dBmW |
| Tx power (max) | -17 dBmW |
| Rx power (max) | -3 dBmW |
| Link budget | 13 dB |
| Networking standards | IEEE 802.3z |
| Fiber ethernet cabling technology | 1000BASE |
| Features | |
| Product colour | Black, Stainless steel |
| Hot-Plug support | Yes |
| Certification | FCC Class B, ICES-003 Class B, CE Class B, VCCI Class B, FDA/CDRH, TUV, cUL |
| Power | |
| Input voltage | 3.3 V |
| Maximum current | 0.24 A |
| Operational conditions | |
| Maximum operating temperature | 70 °C |
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Weight & dimensions | |
| Width | 13.4 mm |
| Depth | 56.4 mm |
| Height | 10.3 mm |
| Weight | 15.5 g |
| Packaging data | |
| Number of products included | 10 pc(s) |
| Technical details | |
| Sustainability compliance | Yes |
| Sustainability certificates | RoHS |
| Other features | |
| RX sensitivity | -17 dB |
