StarTech.com ST1000SPEX43 network card

ST1000SPEX43 - 0065030862448

StarTech.com 4-Port PCIe Gigabit Network Adapter Card


Brand
STARTECH
Product code
ST1000SPEX43
SKU
CAL6VTU6T68ML
EAN/GTIN
0065030862448
  • Add four independent Gigabit RJ45 ports to connect to multiple networks for high-bandwidth workstations and servers
  • Realtek RTL8111G chipset for reliable performance
  • Supports full-duplex flow control
  • Fully compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab networks
  • Supports autonegotiation with next-page capacity
  • Crossover detection and auto-correction (Auto-MDIX)
€176.47 (Inc. VAT)
(Delivery 2-4 working days)

Product Info

StarTech.com 4 Port PCIe Network Card - Standard Profile - RJ45 Port - Realtek RTL8111G Chipset - Ethernet Network Card - NIC Server Adapter Network Card (ST1000SPEX43)

StarTech.com 4-Port PCIe Gigabit Network Adapter Card. Internal. Connectivity technology: Wired, Host interface: PCI Express, Interface: Ethernet. Maximum data transfer rate: 2000 Mbit/s

Add four Gigabit Ethernet ports to a client, server or workstation through one PCI Express slot

Now you can add four separate Gigabit network ports to your client, server or workstation through just one PCI Express slot, to provide connectivity to multiple networks without draining your budget.

Reliable connectivity to multiple networks

This 4-port network card delivers powerful connectivity for your business, corporate or government office environment, with support for high-performance, 4-channel networking and a maximum throughput of up to 1000Mbps in each direction (2000 Mbps total). The network adapter card features the Realtek RTL8111G chipset, which is designed to deliver the performance and enhanced capabilities you need for reliable network connections to your server or computer.

A versatile and cost-effective solution

This versatile quad-port network card is ideal for many business applications requiring upgrades to servers or workstations, adding feature-rich Gigabit networking with four independent ports. Compatible with a broad range of operating systems, this cost-effective PCIe Gigabit NIC is suitable for many SMB and Enterprise applications such as virtualized environments that require multiple NICs (check your VM software for chipset compatibility).

The ST1000SPEX43 is backed by a StarTech.com 2-year hardware warranty and free lifetime technical support.

The StarTech.com Advantage

- Add four independent Gigabit RJ45 ports to connect to multiple networks for high-bandwidth workstations and servers
- Realtek RTL8111G chipset for reliable performance
- Supports full-duplex flow control

Ports & interfaces
Connectivity technology Wired
Host interface PCI Express
Interface Ethernet
Ethernet LAN (RJ-45) ports 4
Network
Maximum data transfer rate 2000 Mbit/s
Networking standards IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Ethernet LAN Yes
Ethernet LAN data rates 10,1000,100 Mbit/s
Cabling technology 10/100/1000BaseT(X)
Wake-on-LAN ready Yes
Auto MDIX IEEE No
Full duplex Yes
Jumbo frames support Yes
Design
Internal Yes
Chipset Realtek RTL8111G
LED indicators Activity, Link
System requirements
Windows operating systems supported Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows XP, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Linux operating systems supported Yes
Server operating systems supported Windows Server 2003, Windows Server 2012, Windows Server 2016, Windows Server 2019
Operational conditions
Operating temperature (T-T) 0 - 55 °C
Storage temperature (T-T) -40 - 75 °C
Operating relative humidity (H-H) 5 - 95%
Sustainability
Sustainability certificates CE, RoHS
Weight & dimensions
Width 120 mm
Depth 138 mm
Height 18 mm
Weight 95 g
Packaging data
Package width 209 mm
Package depth 145 mm
Package height 40 mm
Package weight 184 g
Logistics data
Harmonized System (HS) code 85176990
Master (outer) case width 446 mm
Master (outer) case length 521 mm
Master (outer) case height 344 mm
Products per master (outer) case 50 pc(s)
Other features
Flow control support Yes
Case colour Yellow
