StarTech.com SV565FXHD4KU KVM extender

SV565FXHD4KU - 0065030887694

StarTech.com 4K HDMI KVM Extender over Fiber - HDMI Video & USB Remote KVM Switch/Console Extender - up to 984ft/300m (MultiMode) - 2x 10G MMF SFP+ modules - KVM Extension Kit (TX/RX)

Brand: STARTECH
Product code: SV565FXHD4KU
SKU: ZBK7LY27ZDUPH
EAN/GTIN: 0065030887694

REMOTE ACCESS: USB & 4K HDMI KVM extender over fiber controls a KVM switch/console or PC using a fiber optic cable at distances up to 984'/300m (multimode cable) or 1,640'/500m (single mode cable); open SFP+ slots for use w/ MSA compliant 10G SFP+ modules
4K 60Hz VIDEO: HDMI transmitter and receiver extender kit achieves UHD resolutions up to 3840 x 2160 @ 60Hz, supporting 4:4:4 image sampling for accurate color & image for applications requiring high resolution video like digital signage & security
DIGITAL AUDIO & HDMI 2.0 VIDEO: Keyboard Video Mouse Extender with EDID passthrough transfers display capabilities to the video source, maximizing compatibility between devices; Digital 7.1 surround audio over HDMI for high quality sound; HDCP 2.2 support
SPECS: HDMI 2.0 Fiber Optic KVM Extender / 3x USB 1.1 HID / OS Independent / EDID Passthrough / Supports MM or SM SFP+ / 2x 10G Multimode SFP+ modules inc. / LC Connectors / 300m/984 ft (MM) or 500m/1,640 ft (SM) max extension range / 2 year Warranty
EASY TO DEPLOY: Straightforward point-to-point setup using standard fiber optic cable makes configuration easy using the incl. SFP+ modules; there's no proprietary software and network settings to configure; StarTech.com's tech advisors are available 24/5

€718.39 (Inc. VAT)

(Delivery 2-4 working days)

Product Info

StarTech.com 4K HDMI KVM Extender over Fiber - HDMI Video & USB Remote KVM Switch/Console Extender - up to 984ft/300m (MultiMode) - 2x 10G MMF SFP+ modules - KVM Extension Kit (TX/RX) (SV565FXHD4KU)

StarTech.com 4K HDMI KVM Extender over Fiber - HDMI Video & USB Remote KVM Switch/Console Extender - up to 984ft/300m (MultiMode) - 2x 10G MMF SFP+ modules - KVM Extension Kit (TX/RX). Type: Transmitter & receiver, Connectivity technology: Wired, Maximum transfer distance: 500 m. Transmitter video port type: HDMI. Receiver local video port type: HDMI. AC input voltage: 100 - 240 V, Input current: 0.3 A, AC adapter output voltage: 5 V. Transmitter width: 7.5 cm, Transmitter depth: 10 cm, Transmitter height: 2.8 cm

HDMI KVM Extender Kit | 4K 60Hz | 4:4:4 Chroma Sampling | 2x LC SFP+ (MM) IncludedThe StarTech.com Advantage

Specifications

Features

Type Transmitter & receiver

Connectivity technology Wired

Maximum transfer distance 500 m

Rack mounting No

Maximum digital resolution 3840 x 2160 pixels

Maximum refresh rate 60 Hz

On Screen Display (OSD) No

Product colour Black

Material Metal

USB 1.1 ports quantity 3

LED indicators Power, Status

Transmitter

Transmitter video port type HDMI

Number of displays supported 1

Receiver

Receiver local video port type HDMI

Power

AC input voltage 100 - 240 V

Input current 0.3 A

AC adapter output voltage 5 V

AC adapter output current 2 A

Power consumption (transmitter) (max) 10 W

Power consumption (receiver) (max) 10 W

Operational conditions

Operating temperature (T-T) 0 - 50 °C

Storage temperature (T-T) -10 - 60 °C

Operating relative humidity (H-H) 0 - 80%

Weight & dimensions

Transmitter width 7.5 cm

Transmitter depth 10 cm

Transmitter height 2.8 cm

Transmitter weight 450 g

Receiver width 7.5 cm

Receiver depth 10 cm

Receiver height 2.8 cm

Receiver weight 450 g

Packaging data

Package width 180 mm

Package depth 310 mm

Package height 75 mm

Package weight 140 g

Technical details

Weight 500 g

Sustainability certificates CE, RoHS

Packaging content

AC adapter included Yes

Cables included Mini-USB

Quick installation guide Yes

Logistics data

Harmonized System (HS) code 84733080

Master (outer) case width 405 mm

Master (outer) case length 330 mm

Master (outer) case height 265 mm

Products per master (outer) case 6 pc(s)
