StarTech.com ST1214T AV extender

StarTech.com 4 Port VGA Over CAT5 Video Extender - 450ft (150m)


Brand
STARTECH
Product code
ST1214T
SKU
GYDT1PS5AOV9Z
EAN/GTIN
0065030824446
  • AV transmitter & receiver 1600 x 1200 pixels Black
  • Maximum transfer distance: 150 m
  • DC-in jack
€160.33 (Inc. VAT)
Sold Out
(Delivery 2-4 working days)

Product Info

Extend and distribute a VGA signal to up to 4 displays over Cat5 cable
The ST1214T 4 Port VGA Video Extender over Cat 5 allows a single VGA source to be broadcast to up to four remote displays at distances of up to 500 feet (150 meters). Designed for use with our ST121 VGA Video over Cat 5 extension series of devices, the ST1214T is one of many options designed to help you create a custom VGA distribution and extension solution for many applications including digital signage and video conferencing. Consisting of the transmitter unit only, this product requires a single ST121R receiver unit per remote display that you are connecting. If you are looking for an eight port transmitter solution, we offer our ST1218T 8 port VGA extender unit. For even more versatility, the ST121EXT VGA over Cat 5 Repeater can be used to increase the total VGA extension distance by an additional 500 feet(150 meters), allowing the original VGA signal to be broadcast a total distance of 1000 feet (300 meters) from transmitter to receiver. Similarly, up to three repeater units can be used between the transmitter and receiver units allowing a monitor to be connected at each repeater station , while further extending the total distance between the transmitter and receiver units. Backed by a StarTech.com 2-year warranty and free lifetime technical support.

Features
Type AV transmitter & receiver
Maximum resolution 1600 x 1200 pixels
Cable types supported Cat5, Cat5e, Cat6, Cat6a, Cat6e, Cat7
Maximum transfer distance 150 m
Supported graphics resolutions 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA)
Product colour Black
Ports & interfaces
RJ-45 output ports 4
VGA (D-Sub) input ports 1
VGA (D-Sub) output ports 1
DC-in jack Yes
Power
AC input voltage 100-240 V
Operating voltage 9 V
Current 0.6 A
Weight & dimensions
Dimensions (WxDxH) 63.9 x 103 x 20.6 mm
Weight 246 g
Packaging data
Package width 220 mm
Package depth 101 mm
Package height 98 mm
Package weight 529 g
Technical details
Number of connectors 7
We do not guarantee the completeness and accuracy of the product details, which are obtained from outside sources.
