AOC AS110D0 monitor mount / stand 81.3 cm (32") Desk Black
- Brand
- AOC
- Product code
- AS110D0
- SKU
- 4FRBAGL9P995E
- EAN/GTIN
- 4038986636728
- Maximum weight capacity: 9 kg
- Minimum screen size: 33 cm (13") Maximum screen size: 81.3 cm (32")
- Number of displays supported: 1
- Clamp/Bolt-through Mounting type: Desk
- Maximum VESA mount: 100 x 100 mm
- Gas spring Height adjustment Tilt adjustment
- Cable management
- Aluminium Black
Product Info
Get your monitor in the optimum position easily with AS110's mechanical gas-spring arm
AS110's sleek and sturdy, gas-spring controlled monitor arm enables wide range of ergonomics for your VESA (75 mm or 100 mm) supported monitor. Free up your desk with integrated cable managament. Supports up to 27", 9 kg monitors and offers 320 mm height, 325 mm stretch, -45°/60° tilt, -90°/90° swivel and 360° pivot range for increased flexibility.
Description
Swivel & Tilt
Some monitor stands come with a limited tilt and swivel range. Using a monitor arm increases your monitor’s range of motion dramatically: You can tilt the monitor in a wide range so it points upwards or downwards for the optimal viewing angle. The integrated swivel enables you to turn the display horizontally.
C-Lamp or Grommet Mount attachment
Your new AOC monitor arm is guaranteed to fit onto your desk. With either the grommet mount or the c-lamp method, you can easily fasten the mount to your tabletop. Your monitor will be firmly secured and ready for every gaming action.
Mechanical Gas Spring System
Smooth motion in extension, retraction, or changing orientation. The precise mechanical gas-spring allows easy adjustment with just a firm hand move, and the monitor stays sturdily in its adjusted position. Easily adjust it anytime to get the most ergonomic position. Spring tension is adjustable for lighter/heavier monitors for easy movement and firmness.
Cable Management
Using the detachable covers on the monitor arm, simply push through your cables inside the pre-allocated routes in the monitor arm. After fitting both power and display cables inside, close the covers and experience a tidy desk with neatly organised connections. Cables are kept in place even when moving the display or turning it into portrait mode.
Vesa Connection
Any monitor equipped with a VESA mounting grid (100x100 or 75x75) can easily be attached to the monitor arm. The VESA mounting system is a widely used solution that most monitors are equipped with. Four screws hold the monitor securely to the mount, by its centre of gravity.
| Mounting | |
|---|---|
| Minimum screen size | 33 cm (13") |
| Maximum weight capacity | 9 kg |
| Maximum screen size | 81.3 cm (32") |
| Mounting | Clamp/Bolt-through |
| Minimum VESA mount | 75 x 75 mm |
| Maximum VESA mount | 100 x 100 mm |
| Panel mounting interface | 75 x 75,100 x 100 mm |
| Number of displays supported | 1 |
| Clamp mount desk thickness (max) | 10.5 cm |
| Grommet mount desk thickness (max) | 8.3 cm |
| Mounting hole range | 7 - 87 mm |
| Mounting type | Desk |
| Ergonomics | |
| Height adjustment | Yes |
| Height adjustment type | Gas spring |
| Adjustable depth | Yes |
| Depth adjustment range | 0 - 460 mm |
| Tilt angle range | -45 - 60° |
| Swivel angle range | -90 - 90° |
| Pivot angle | 0 - 360° |
| Cable management | Yes |
| Tilt adjustment | Yes |
| Design | |
| Housing material | Aluminium |
| Product colour | Black |
| Technical details | |
| Height adjustment | 32 cm |
| Pivot | Yes |
| Weight (with stand) | 2.4 kg |
| Adjustment type | Gas spring |
| Display diagonal | 68.6 cm (27") |
| Weight & dimensions | |
| Width | 280 mm |
| Depth | 120 mm |
| Height | 410 mm |
| Weight | 2.4 kg |
| Package width | 280 mm |
| Package depth | 120 mm |
| Package height | 410 mm |
| Package weight | 3 kg |
| Packaging content | |
| Packaging content | User Manual, Monitor Arm, Clamp mount, Grommet mount, Installation materials |
| Logistics data | |
| Harmonized System (HS) code | 85299097 |
| Other features | |
| Height (max) | 58 cm |
| VESA mounting | Yes |
