StarTech.com VGA to RCA and S-Video Converter - USB Power
- Brand
- STARTECH
- Product code
- VGA2VID2
- SKU
- XNDGR64OXUC66
- EAN/GTIN
- 0065030882590
- Provides output in both Composite and S-Video formats
- Supports PC input resolutions up to 1920 x 1080
- Select between NTSC and PAL outputs
- Dynamically adjust image underscan and overscan
- Powered by USB port
Product Info
Computer to TV Converter | 1080p to 480i Scaler |Composite & S-Video | 2-Year Warranty
This VGA to RCA/S-Video converter box provides a simple way to convert and scale a 1080p VGA video input signal to a 480i composite (CVBS) or S-Video output signal. Perfect for use with legacy projectors or TV sets.
Hassle-Free Setup and Easy to Use
Equipped with a NTSC/PAL toggle switch and a scan button for simple configuration and selection of your video output settings, this compact VGA to Composite and S-Video adapter installs quickly and easily, for a true plug-and-play experience.
Save on Upgrade Costs
By using this VGA to AV adapter you can connect a PCs VGA connector to legacy TVs and projectors, ultimately saving the costs of upgrading your equipment. It's ideal for boardroom settings, medical imaging and watching videos on your S-Video or Composite display.
Crystal-Clear Picture Quality
The PC to television converter features an integrated video scaler circuit that dynamically converts VGA video input signals with resolutions up to 1920x1200 @ 60Hz. To ensure compatibility with your display or projector the computer to TV converter outputs high quality 720 x 480 video, the highest supported by S-Video or Composite.
VGA2VID2 is backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
- Provides output in both Composite and S-Video formats
- Supports PC input resolutions up to 1920 x 1080
- Select between NTSC and PAL outputs
| Features | |
|---|---|
| Converter type | Active video converter |
| Product colour | Black |
| Certification | CE, FCC, REACH |
| Video | |
| Maximum video resolution | 1920 x 1080 pixels |
| Video Resolutions | 640 x 480,1920 x 1080 pixels |
| Maximum refresh rate | 60 Hz |
| Ports & interfaces | |
| Host interface | VGA (D-Sub) |
| Output interface | Composite/S-Video |
| Power | |
| USB powered | Yes |
| Power consumption (typical) | 2.5 W |
| Technical details | |
| Sustainability certificates | RoHS |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -10 - 80 °C |
| Operating relative humidity (H-H) | 5 - 90% |
| Weight & dimensions | |
| Width | 54 mm |
| Depth | 60 mm |
| Height | 20 mm |
| Weight | 46 g |
| Packaging data | |
| Cables included | USB |
| Quick installation guide | Yes |
| Quantity | 1 |
| Package width | 133 mm |
| Package depth | 105 mm |
| Package height | 24 mm |
| Package weight | 162 g |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Master (outer) case width | 540 mm |
| Master (outer) case length | 568 mm |
| Master (outer) case height | 351 mm |
| Products per master (outer) case | 100 pc(s) |
