TP-Link SM6110-LR network transceiver module
SM6110-LR - 8885020622362
TP-Link SM6110-LR network transceiver module Fiber optic 25780 Mbit/s SFP+ 1310 nm
- Brand
- TP-Link
- Product code
- SM6110-LR
- SKU
- NMNHRDS7LF4AU
- EAN/GTIN
- 8885020622362
- Single-mode SFP+/SFP28 LC Transceiver
- Hot-Pluggable with maximum flexibility
- Supports Digital Diagnostic Monitoring (DDM)
- Low Power Consumption no more than 1.2 W
- Compatible with 10G/25G Small Form Pluggable Multi-Source Agreement (SFP+/SFP28 MSA)
- Compatible with switches with 25G ports like SX6632YF; and 10G ports like SG3428X and SG3452X
€96.53
(Inc. VAT)
(Delivery 2-4 working days)
Product Info
Omada 25GBase-LR SFP28 LC Transceiver
TP-Link SM6110-LR. SFP transceiver type: Fiber optic, Maximum data transfer rate: 25780 Mbit/s, Interface type: SFP+. Product colour: Grey. Input voltage: 3.3 V. Width: 57 mm, Depth: 14 mm, Height: 12 mm. Quantity per pack: 1 pc(s)
The SM6110-LR is designed to extend transfer distances based on 10G/25G Ethernet connectivity. It is a 10G/25GBASE-LR high performance 1310 nm single-mode SFP+/SFP28 transceiver. It supports full duplex, 10G/25G Ethernet connections up to 10 km with 9/125µm fiber cables respectively.
Specifications
Performance
SFP transceiver type
Fiber optic
Maximum data transfer rate
25780 Mbit/s
Interface type
SFP+
Wavelength
1310 nm
Features
Product colour
Grey
Hot-Plug support
Yes
Power
Input voltage
3.3 V
Operational conditions
Maximum operating temperature
70 °C
Storage temperature (T-T)
-40 - 85 °C
Storage relative humidity (H-H)
5 - 90%
Weight & dimensions
Width
57 mm
Depth
14 mm
Height
12 mm
Packaging data
Number of products included
1 pc(s)
