D-Link 10G Layer 3 Stackable Managed SFP+ Switch
- Brand
- D-Link
- Product code
- DXS-3410-32SY/B
- SKU
- MA9375XP24VAO
- High Availability and Flexibility
- Variety of high-speed interface combinations to meet different network requirements
- 24 Multi-Gigabit 100M/1/2.5/5/10GBASE-T ports
- 28 SFP+ ports
- 4 10/25G SFP28 ports Reliability
- Redundant power supply (RPS) support
- Ethernet Ring Protection Switching (ERPS)
- IEEE 802.1D/802.1w/802.1s Spanning Tree
- Loopback Detection (LBD)
- Smart fan with Quiet mode design L3 Features
- Static Route
- RIP/RIPng
- OSPFv2/v3 Lossless Ethernet via Data Center Bridging (DCB)
- IEEE 802.1Qbb Priority-based Flow Control (PFC) Operations, Administration and Maintenance
- IEEE 802.3ah Ethernet Link OAM
- IEEE 802.1ag/ITU-T Y.1731 Service OAM High Bandwidth Stacking
- Physical stack of up to 9 units via four 25G ports
- Supports long-distance stacking over fiber
- 200 Gbps per device physical stacking bandwidth
Product Info
The DXS-3410 Series is a range of 10G Layer 3 Stackable Managed Switches designed to connect end-users in a secure enterprise or metro Ethernet access network. These switches support both multicasting and enhanced security, making them an ideal multi-Gigabit access layer solution. The DXS-3410 Series is equipped with multi-Gigabit Ethernet and SFP+ network connection options and includes models equipped with multi-Gigabit Ethernet and SFP28 network connection capabilities. Each model boasts 10G fiber ports and four 10/25G SFP28 ports to provide versatility and speed. This series is also equipped with a USB 2.0 port, allowing users to boot images and upload configuration files directly from, as well as conveniently save syslog files to a USB 2.0 storage device
| Management features | |
|---|---|
| Switch type | Managed |
| Switch layer | L2+/L3 |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | 10G Ethernet (100/1000/10000) |
| Network | |
| 10G support | Yes |
| Data transmission | |
| Switching capacity | 760 Gbit/s |
| MAC address table | 32000 entries |
| Design | |
| Rack mounting | Yes |
| Stackable | Yes |
| Power | |
| Power source | AC |
| Power supply included | Yes |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Yes |
