TP-Link Omada SG2428LP network switch

SG2428LP - 8885020620849

TP-Link Omada 28-Port Gigabit Smart Switch with 16-Port PoE+

Brand: TP-Link
Product Family: Omada
Product code: SG2428LP
SKU: 02JR75STXS03X
EAN/GTIN: 8885020620849

16× Gigabit 802.3af/at PoE+ ports
8× Gigabit non-PoE RJ45 ports and 4× Gigabit SFP slots
150 W total PoE budget with up to 30 W PoE output per port*
Centralized cloud management via the web or the Omada app†
Standalone management via web, CLI, SNMP, and RMON
Static Routing helps route internal traffic for higher efficiency
VLAN, ACL, QoS, and IGMP Snooping
Fanless design for quiet operation
Durable metal casing and rackmountable design

€279.56 (Inc. VAT)

Sold Out

(Delivery 2-4 working days)

Product Info

16× 10/100/1000 Mbps PoE+ RJ45, 8× 10/100/1000 Mbps RJ45, 4× Gigabit SFP Slots, 56 Gbps, 41.66 Mpps, 440 x 220 x 44 mm

TP-Link Omada 28-Port Gigabit Smart Switch with 16-Port PoE+. Switch type: Managed, Switch layer: L2/L2+. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24. MAC address table: 8000 entries, Switching capacity: 56 Gbit/s. Networking standards: IEEE 802.3af, IEEE 802.3at. Power over Ethernet (PoE). Rack mounting

- 24× Gigabit Ports (16× PoE+), 4× Gigabit SFP Slots
- 150 W Total PoE Budget
- Fanless Design for Silent Operation
- Zero-Touch Provisioning
- Centralized Management
- Omada App
- Static Routing
- Traffic Separation

Software Defined Networking (SDN) with Cloud Access
Remotely manage your access points, switches, and gateways across multiple sites all from a single interface.

Multiple Application Scenarios

Surveillance
Works with IP Cameras

Conference Call
Works with IP Phones

Wi-Fi Coverage
Works with Access Points

Wired Connections
Works with Non-PoE Devices such as PCs and Printers

Specifications

Management features

Switch type Managed

Switch layer L2/L2+

Quality of Service (QoS) support Yes

Web-based management Yes

Cloud-managed Yes

ARP inspection Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity 24

Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)

SFP module slots quantity 4

Network

Networking standards IEEE 802.3af, IEEE 802.3at

10G support No

Flow control support Yes

Link aggregation Yes

Spanning tree protocol Yes

Auto-negotiation Yes

VLAN support Yes

Virtual LAN features MAC address-based VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN

Number of VLANs 4000

Data transmission

Switching capacity 56 Gbit/s

Forwarding rate 41.66 Mpps

MAC address table 8000 entries

Jumbo frames support Yes

Jumbo frames 9000

Packet buffer memory 4.1 MB

Security

DHCP features DHCP relay, DHCP server

Access Control List (ACL) Yes

IGMP snooping Yes

MAC address filtering Yes

Password protection Yes

Multicast features

Multicast support Yes

Design

Rack mounting Yes

Product colour Grey

LED indicators Yes

Performance

Fanless Yes

Power

Power source AC/PoE

AC input voltage 100 - 240 V

AC input frequency 50/60 Hz

Power consumption (max) 184.7 W

Power over Ethernet (PoE)

Power over Ethernet (PoE) Yes

Power over Ethernet plus (PoE+) ports quantity 16

Power over Ethernet (PoE) power per port 30 W

Total Power over Ethernet (PoE) budget 150 W

Operational conditions

Operating temperature (T-T) 0 - 40 °C

Storage temperature (T-T) -40 - 70 °C

Operating relative humidity (H-H) 10 - 90%

Storage relative humidity (H-H) 5 - 90%

Heat dissipation 628 BTU/h

Weight & dimensions

Width 440 mm

Depth 220 mm

Height 44 mm
