ASUS NUC 12 RNUC12WSHi50000I

90AR00E1-M00060 - 4711387504918

ASUS NUC 12 RNUC12WSHi50000I UCFF Black

Brand: Asus
Product Family: NUC 12
Product series: Pro Kit
Product code: 90AR00E1-M00060
SKU: ZTZHJ0N7U9BK3
EAN/GTIN: 4711387504918

UCFF Black
Built-in processor Intel
2 SO-DIMM Maximum internal memory: 64 GB DDR4-SDRAM
SSD M.2
Intel Iris Xᵉ Graphics
Ethernet LAN Wi-Fi

€458.22 (Inc. VAT)

Sold Out

(Delivery 2-4 working days)

Product Info

NUC 12 Pro Kit, Intel Core i5, Up to 64 GB dual-channel DDR4-3200 SODIMMs

ASUS NUC 12 RNUC12WSHi50000I. Chassis type: UCFF, Product type: Mini PC barebone. Supported memory types: DDR4-SDRAM, Number of memory slots: 2, Maximum internal memory: 64 GB. Supported storage drive types: SSD. Ethernet LAN (RJ-45) ports: 1. Wi-Fi standards: Wi-Fi 6E (802.11ax), Bluetooth version: 5.2. Cooling type: Active

Built for Business. NUC 12 Pro
Boost business performance with 12th Gen Intel® Core™ processors and the latest features to support productivity, collaboration, and edge compute.

NUC 12 Pro Mini PCs, Kits, & Boards
Ready to work, wherever it’s needed—the 4x4 compact device is designed to go where you go, and fit into any space.

Surprising size. Supercharged performance
Level up your business with the latest technologies.

Specifications

Processor

Processor manufacturer Intel

Processor family Intel® Core™ i5

Processor generation 12th gen Intel® Core™ i5

Built-in processor Yes

Memory

Memory slots type SO-DIMM

Number of memory slots 2

Maximum internal memory 64 GB

Supported memory clock speeds 3200 MHz

Supported memory types DDR4-SDRAM

Memory voltage 1.2 V

ECC No

Storage

Supported storage drive types SSD

Storage drive sizes supported M.2

SSD form factor M.2

NVMe Yes

Number of storage drives supported 2

Graphics

On-board graphics card No

Graphics card family Intel

On-board graphics card model Intel Iris Xe Graphics

Number of displays supported 4

Audio

Built-in speaker(s) No

Network

Top Wi-Fi standard Wi-Fi 6E (802.11ax)

Wi-Fi standards Wi-Fi 6E (802.11ax)

WLAN controller model Intel Wi-Fi 6E AX211

Ethernet LAN Yes

Wi-Fi Yes

LAN controller Intel I225-V

Bluetooth Yes

Bluetooth version 5.2

Ports & interfaces

USB 2.0 ports quantity 1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 3

HDMI ports quantity 2

HDMI version 2.1

Combo headphone/mic port Yes

Ethernet LAN (RJ-45) ports 1

Serial port via internal header No

Thunderbolt 4 ports quantity 2

DC-in jack Yes

Expansion slots

PCI Express slots version 4.0

Design

Chassis type UCFF

Product colour Black

Cooling type Active

On/off switch Yes

LED indicators Yes

VESA mounting Yes

Product type Mini PC barebone

Performance

Motherboard form factor UCFF

Number of processors supported 1

Software

Windows operating systems supported Windows 11 Home, Windows 11 Pro, Windows 10 Home, Windows 10 IoT Enterprise, Windows 10 Pro

Linux operating systems supported Yes

Power

Power supply type External AC adapter

Weight & dimensions

Width 117 mm

Depth 112 mm

Height 37 mm
