TP-Link Omada SG2452LP network switch

SG2452LP - 8885020620825

TP-Link Omada 52-Port Gigabit Smart Switch with 32-Port PoE+

Brand: TP-Link
Product Family: Omada
Product code: SG2452LP
SKU: JFNFIC6KR3W5D
EAN/GTIN: 8885020620825

32× Gigabit 802.3af/at PoE+ ports
16× Gigabit non-PoE RJ45 ports and 4× Gigabit SFP slots
230 W total PoE budget with up to 30 W PoE output per port*
Centralized cloud management via the web or the Omada app†
Standalone management via web, CLI, SNMP, and RMON
Static Routing helps route internal traffic for higher efficiency
VLAN, ACL, QoS, and IGMP Snooping
Fanless design for quiet operation
Durable metal casing and rackmountable design

€567.17 (Inc. VAT)

Sold Out

(Delivery 2-4 working days)

Product Info

32× 10/100/1000 Mbps PoE+ RJ45, 16× 10/100/1000 Mbps non-PoE RJ45, 4× Gigabit SFP, 104 Gbps, 16 K MAC, 9 KB Jumbo, 440x330x44 mm

TP-Link Omada 52-Port Gigabit Smart Switch with 32-Port PoE+. Switch type: Managed, Switch layer: L2/L2+. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 48. MAC address table: 16000 entries, Switching capacity: 104 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3x. Power connector: AC-in jack. Power over Ethernet (PoE). Rack mounting, Form factor: 1U

Power over Ethernet, Flexible Network Deployment

Easily Build a Whole 10G Multi-gigabit Network

Software Defined Networking (SDN) with Cloud Access
Remotely manage your access points, switches, and gateways across multiple sites all from a single interface.

Specifications

Management features

Switch type Managed

Switch layer L2/L2+

Quality of Service (QoS) support Yes

Web-based management Yes

Cloud-managed Yes

ARP inspection Yes

Configuring Location Settings (CLI) Yes

System event log Yes

MIB support Y

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity 48

Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)

SFP module slots quantity 4

Power connector AC-in jack

Network

Networking standards IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3x

10G support No

Port mirroring Yes

IP routing Yes

Flow control support Yes

Link aggregation Yes

Auto MDI/MDI-X Yes

Ethernet LAN data rates 10,100,1000 Mbit/s

Active link detection Yes

VLAN support Yes

Data transmission

Switching capacity 104 Gbit/s

Forwarding rate 77.37 Mpps

MAC address table 16000 entries

Static route Yes

Jumbo frames support Yes

Jumbo frames 9000

Security

DHCP features DHCP relay, DHCP server

IGMP snooping Yes

Security algorithms SNMP, SNMPv2, SNMPv3

MAC address filtering Yes

SSH/SSL support Yes

Loop protection Yes

Authentication type RADIUS

Design

Rack mounting Yes

Form factor 1U

Product colour Black

LED indicators Yes

Power

Power source AC

Power supply included Yes

AC input voltage 100 - 240 V

AC input frequency 50/60 Hz

Power consumption (max) 304.5 W

Power over Ethernet (PoE)

Power over Ethernet (PoE) Yes

Power over Ethernet plus (PoE+) ports quantity 32

Power over Ethernet (PoE) power per port 30 W

Total Power over Ethernet (PoE) budget 230 W

Operational conditions

Operating temperature (T-T) 0 - 40 °C

Storage temperature (T-T) -40 - 70 °C

Operating relative humidity (H-H) 10 - 90%

Storage relative humidity (H-H) 5 - 90%

Heat dissipation 1035.4 BTU/h

Weight & dimensions

Width 440 mm

Depth 330 mm

Height 44 mm
