Viewsonic LDM163-182 Signage Display
Viewsonic LDM163-182 Signage Display Digital signage flat panel 4.14 m (163") LED Wi-Fi 600 cd/m² Black Android 9
- Brand
- ViewSonic
- Product code
- LDM163-182
- SKU
- AYGUFZKONPGYT
- EAN/GTIN
- 766907026535
- Seamless and Immersive Screen
- Flexible Installation with Detachable System Control Box
- Durable Glue-on Board Surface Treatment
- Easy Content Sharing
- Centralized Management via LAN Control
- Hassle-Free Installation & Maintenance
€62126.17
(Inc. VAT)
Sold Out
(Delivery 2-4 working days)
Product Info
Viewsonic LDM163-182. Product design: Digital signage flat panel. Display diagonal: 4.14 m (163"), Display technology: LED, Display resolution: 1920 x 1080 pixels, Display brightness: 600 cd/m². Wi-Fi. Operating system installed: Android 9. Product colour: Black
The ViewSonic® LDM163-182 is an innovative All-in-One Direct View LED display. With a huge 163” screen size, the LDM163-182 is built to impress as a centerpiece in any higher education auditorium or lecture hall, as well as in corporate conference rooms, boardrooms and lobbies. This display boasts immersive and stunning visuals thanks to Full HD resolution that pairs perfectly with an impressive 600-nit high brightness. This ensures content and messages are always easy to see, even in brightly lit environments. A sleek design and innovative detachable control box delivers a 99% screen-to-body ratio, allowing the display to seamlessly blend into any space while keeping the controls conveniently accessible. Plus, a Glue-on-Board (GOB) LED surface treatment delivers an IP54 rating for enhanced protection from collisions, dust and moisture. With seamless installation, 24/7 reliability, and purposefully designed features for high-impact messaging and digital signage applications, this display sets a new standard for visual excellence at an unbeatable value.
| Display | |
|---|---|
| LED backlight | Yes |
| LED backlighting type | Direct-LED |
| Display diagonal | 4.14 m (163") |
| Display technology | LED |
| Display resolution | 1920 x 1080 pixels |
| Display brightness | 600 cd/m² |
| Contrast ratio (typical) | 6500:1 |
| Viewing angle, horizontal | 170° |
| Viewing angle, vertical | 170° |
| Active display area (W x H) | 3600 x 2025 mm |
| Panel life | 100000 h |
| Horizontal scan range | 31 - 94 kHz |
| Vertical scan range | 56 - 85 Hz |
| Ports & interfaces | |
| HDMI ports quantity | 5 |
| HDMI version | 2.0 |
| HDMI input ports quantity | 4 |
| HDMI output ports quantity | 1 |
| USB port | Yes |
| USB ports quantity | 2 |
| USB version | 3.0 |
| USB connector type | USB Type-A, USB Type-C |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 3 |
| Wi-Fi | Yes |
| Audio (L/R) out | 2 |
| RS-232 interface | Yes |
| Infrared data port | Yes |
| Remote (IR) input | 1 |
| Remote (IR) output | 1 |
| Audio | |
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 2 |
| RMS rated power | 30 W |
| Design | |
| Product design | Digital signage flat panel |
| Product colour | Black |
| Mounting type | Wall |
| Performance | |
| Purpose | Commercial |
| International Protection (IP) code | IP54 |
| Power | |
| Power consumption (typical) | 919 W |
| Input voltage | 100-120 V |
| Power consumption (sleep) | 0.5 W |
| Power consumption (max) | 2642 W |
| AC input voltage | 220 - 240 V |
| AC input frequency | 50 Hz |
| Computer system | |
| Internal storage capacity | 32 GB |
| Operating system installed | Android 9 |
| Weight & dimensions | |
| Display width | 3612 mm |
| Display depth | 31 mm |
| Display height | 2171 mm |
| Weight (with stand) | 227 kg |
| Packaging data | |
| Package width | 2250 mm |
| Package depth | 1000 mm |
| Package height | 1240 mm |
| Package weight | 361 kg |
| Packaging content | |
| Remote control included | Yes |
| Cables included | IR, LAN (RJ-45), Power |
| Mounting kit | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Features | |
| Wall mountable | Yes |
