Viewsonic VPC12-WPO-16 embedded computer

VPC12-WPO-16 - 766907017588

Viewsonic VPC12-WPO-16 embedded computer 2.3 GHz Intel® Core™ i5 256 GB SSD 8 GB

Brand: ViewSonic
Product code: VPC12-WPO-16
SKU: FKN6XZ2Z5C61Z
EAN/GTIN: 766907017588

High Definition Audio Stereo
Intel HD graphic 655
Max Resolution up to 4096x2304@60Hz

€1173.51 (Inc. VAT)

Sold Out

(Delivery 2-4 working days)

Product Info

Windows 10, Intel Core i5-8259U, DDR4 8GB, 256GB, M.2, Microphone, HDMI x1, Audio line out, x4 USB 3.0 Type-A, x1 Type-C, 12 / 19V, 65W, 202 x 119 x 30mm, 800g

Viewsonic VPC12-WPO-16. Processor frequency: 2.3 GHz, Processor family: Intel® Core™ i5, Processor manufacturer: Intel. Internal memory: 8 GB, Internal memory type: DDR4-SDRAM, Memory slots: 1x SO-DIMM. Total storage capacity: 256 GB, Storage media: SSD, SSD interface: M.2. On-board graphics card model: Intel Iris Plus Graphics 655, Maximum on-board graphics card memory: 32 GB. Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)

The ViewSonic® VPC12-WPO-16 slot-in PC is the ideal integrated solution for the ViewBoard® interactive displays and presentation displays. With dual-band Wi-Fi and Bluetooth, a powerful Intel® Core™ i5-8259U Processor, 8GB DDR4 SO-DIMM memory, and 256GB SSD storage, the VPC12-WPO-16 contains the computing power needed to operate CPU intensive applications.

Specifications

Processor

Processor manufacturer Intel

Processor generation 8th gen Intel® Core™ i5

Processor frequency 2.3 GHz

Processor family Intel® Core™ i5

Processor model i5-8259U

Processor cores 4

Processor boost frequency 3.8 GHz

Processor cache 6 MB

System bus rate 4 GT/s

Processor threads 8

Thermal Design Power (TDP) 28 W

Configurable TDP-down frequency 1.1 GHz

Configurable TDP-down 20 W

Maximum internal memory supported by processor 32 GB

Memory

Internal memory 8 GB

Internal memory type DDR4-SDRAM

Memory slots 1x SO-DIMM

Storage

Total storage capacity 256 GB

Storage media SSD

Number of storage drives installed 1

SSD interface M.2

SSD capacity 256 GB

Graphics

On-board graphics card Yes

On-board graphics card model Intel Iris Plus Graphics 655

Maximum on-board graphics card memory 32 GB

On-board graphics card 4K support Yes

Discrete graphics card No

Graphics card HDMI ports quantity 1

Network

Wi-Fi Yes

Wi-Fi standards 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)

Bluetooth Yes

Bluetooth version 4.2

Bluetooth Low Energy (BLE) Yes

Ports & interfaces

USB 2.0 ports quantity 1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 4

HDMI ports quantity 1

HDMI version 1.4

Performance

Built-in display No

Product colour Black

Software

Operating system installed Windows 10 Pro

Operating system architecture 64-bit

Processor special features

Intel Flex Memory Access Yes

Enhanced Intel SpeedStep Technology Yes

Execute Disable Bit Yes

Idle States Yes

Intel Trusted Execution Technology No

Intel VT-x with Extended Page Tables (EPT) Yes

Embedded options available No

Intel TSX-NI No

Intel 64 Yes

Intel Stable Image Platform Program (SIPP) No

Intel Virtualization Technology for Directed I/O (VT-d) Yes

Intel Clear Video Technology Yes

Intel Software Guard Extensions (Intel SGX) Yes

Intel Virtualization Technology (VT-x) Yes

Power

Power consumption (typical) 65 W

DC input voltage 12 / 19 V

Operational conditions

Operating temperature (T-T) -5 - 45 °C

Operating relative humidity (H-H) 10 - 90%

Certificates

Certification CE EMC, CE LVD, CE RED, RoHS, WEEE, BIS, WPC

Weight & dimensions

Width 202 mm

Depth 119 mm

Height 30 mm

Weight 800 g

Package width 254 mm

Package depth 196 mm

Package height 77 mm

Package weight 1.1 kg
