Samsung QB85R-BD
Samsung QB85R-BD Digital signage flat panel 2.16 m (85") LCD Wi-Fi 350 cd/m² 4K Ultra HD Black Built-in processor Tizen 4.0 16/7
- Brand
- Samsung
- Product Family
- QBR-BD
- Product code
- LH85QBRBDGCXEN
- SKU
- 28AJ8EC0RFBXW
- EAN/GTIN
- 8806094749328
- Indoor Digital signage flat panel Black
- 2.16 m (85") 3840 x 2160 pixels LCD 350 cd/m²
- 6 ms
- Ethernet LAN Wi-Fi
€3154.48
(Inc. VAT)
(Delivery 2-4 working days)
| Display | |
|---|---|
| Panel type | VA |
| Display diagonal | 2.16 m (85") |
| Display technology | LCD |
| Display resolution | 3840 x 2160 pixels |
| Display brightness | 350 cd/m² |
| HD type | 4K Ultra HD |
| Touchscreen | No |
| Response time | 6 ms |
| Contrast ratio (typical) | 4000:1 |
| Dynamic contrast ratio marketing name | Mega Contrast |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Pixel pitch | 0.4875 x 0.4875 mm |
| Horizontal scan range | 30 - 81 kHz |
| Vertical scan range | 48 - 75 Hz |
| Haze rate | 2% |
| Pixel frequency (max) | 594 MHz |
| RGB colour space | DCI-P3 |
| Colour gamut | 92% |
| Ports & interfaces | |
| HDMI ports quantity | 2 |
| HDMI version | 2.0 |
| HDMI input ports quantity | 2 |
| DVI port | Yes |
| USB port | Yes |
| USB ports quantity | 2 |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Wi-Fi | Yes |
| PC Audio in | Yes |
| RS-232 interface | Yes |
| Infrared data port | Yes |
| Remote (IR) input | 1 |
| Audio | |
| Built-in speaker(s) | No |
| Design | |
| Product design | Digital signage flat panel |
| Placement supported | Indoor |
| Product colour | Black |
| Screen shape | Flat |
| VESA mounting | Yes |
| Panel mounting interface | 600 x 400 mm |
| Bezel width (bottom) | 1.29 cm |
| Bezel width (side) | 1.09 cm |
| Bezel width (top) | 1.09 cm |
| Bezel colour | Charcoal Black |
| Performance | |
| Purpose | Universal |
| Operating hours (hours/days) | 16/7 |
| HDCP | Yes |
| HDCP version | 2.2 |
| Power | |
| Power consumption (typical) | 198 W |
| Power consumption (sleep) | 0.5 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Computer system | |
| Computer system | Yes |
| Computer system type | System on Chip (SoC) |
| Built-in processor | Yes |
| Operating system installed | Tizen 4.0 |
| Weight & dimensions | |
| Display width | 1897.8 mm |
| Display depth | 56.7 mm |
| Display height | 1080.8 mm |
| Display weight | 48.4 kg |
| Packaging data | |
| Package width | 2090 mm |
| Package depth | 260 mm |
| Package height | 1247 mm |
| Package weight | 63.7 kg |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Certificates | |
| Certification | Class A 60950-1, 62368-1 |
| Technical details | |
| Audio out (mini jack) | 1 |
| Other features | |
| Bluetooth | Yes |
| Flash memory | 8000 MB |
| RS-232 input ports | 1 |
| RS-232 output ports | 1 |
| RJ-45 input ports | 1 |
| Optional features | WMN8200SG |
