Samsung QB13R-TM

Display

Panel type ADS

Display diagonal 33 cm (13")

Display technology LED

Display resolution 1920 x 1080 pixels

Display brightness 500 cd/m²

HD type Full HD

Touchscreen Yes

Multi-touch Yes

Response time 30 ms

Contrast ratio (typical) 600:1

Contrast ratio (dynamic) 10000:1

Viewing angle, horizontal 178°

Viewing angle, vertical 178°

Pixel pitch 0.153 x 0.153 mm

Horizontal scan range 30 - 81 kHz

Vertical scan range 48 - 75 Hz

Haze rate 25%

Pixel frequency (max) 594 MHz

Colour gamut 45%

Ports & interfaces

HDMI ports quantity 1

HDMI version 1.4

HDMI input ports quantity 1

USB port Yes

USB ports quantity 1

Ethernet LAN Yes

Ethernet LAN (RJ-45) ports 1

Wi-Fi Yes

RS-232 interface Yes

DC-in jack Yes

Design

Product design Interactive flat panel

Placement supported Indoor

Product colour Black

Screen shape Flat

VESA mounting Yes

Panel mounting interface 100 x 100 mm

Bezel width (bottom) 1.31 cm

Bezel width (side) 1.31 cm

Bezel width (top) 1.31 cm

Bezel colour Charcoal Black

Performance

Purpose Universal

Operating hours (hours/days) 16/7

HDCP Yes

HDCP version 2.2

Power

Power consumption (typical) 27.5 W

Power consumption (sleep) 0.5 W

AC input voltage 100 - 240 V

AC input frequency 50/60 Hz

Computer system

Computer system Yes

Computer system type System on Chip (SoC)

Built-in processor Yes

Operating system installed Tizen 4.0

Weight & dimensions

Display width 322 mm

Display depth 29.8 mm

Display height 193.5 mm

Display weight 1.1 kg

Packaging data

Package width 376 mm

Package depth 248 mm

Package height 132 mm

Package weight 2 kg

Operational conditions

Operating temperature (T-T) 0 - 40 °C

Operating relative humidity (H-H) 10 - 80%

Certificates

Certification Class B 60950-1, 62368-160950-1, 62368-1

Technical details

Audio out (mini jack) 1

Other features

Flash memory 8000 MB

RS-232 input ports 1

RJ-45 input ports 1
