APC G3HT10KHB1S uninterruptible power supply (UPS)
G3HT10KHB1S - 0731304285472
APC G3HT10KHB1S uninterruptible power supply (UPS) Double-conversion (Online) 10 kVA 8000 W 2 AC outlet(s)
- Brand
- APC
- Product code
- G3HT10KHB1S
- SKU
- 8FOAV2JGPVRWY
- EAN/GTIN
- 0731304285472
- Double-conversion (Online)
- 10 kVA 8000 W
- Waveform: Sine
- 2 AC outlet(s)
- Sealed Lead Acid (VRLA) 192 V
- Tower Black
Product Info
10kVA, 8kW, 323-477V, 45/65V, 54.5dB, 400x950x130mm, 218kg, Black
APC G3HT10KHB1S. UPS topology: Double-conversion (Online), Output power capacity: 10 kVA, Output power: 8000 W. AC outlet types: Hard Wire 5-wire (3PH + N + G), Terminal, Power plug: Terminal, AC outlets quantity: 2 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery voltage: 192 V, Battery life (max): 5 year(s). Form factor: Tower, Product colour: Black, Display type: LCD. Compliance certificates: RoHS, Certification: CE, EN/IEC 62040-1-1, EN/IEC 62040-2, EN/IEC 62040-3, IEC 61000-4-5, IEC 62040-2, TUV, VFI-SS-111
MGE Galaxy 300 10kVA 400V 3:3 with 10min Battery, Start-up 5x8
Effective three phase power protection against downtime and data loss for mission critical applications. Ruggedized version including dust filter and conformance coated boards for harsh environments.
| Features | |
|---|---|
| UPS topology | Double-conversion (Online) |
| Output power capacity | 10 kVA |
| Output power | 8000 W |
| Waveform | Sine |
| Input operation voltage (min) | 323 V |
| Input operation voltage (max) | 477 V |
| Input frequency | 45/65 Hz |
| Output operation voltage (min) | 380 V |
| Output operation voltage (max) | 415 V |
| Output frequency | 50/60 Hz |
| Input power factor | 0.92 |
| Crest factor | 2.5:1 |
| Emergency Power Off (EPO) | Yes |
| Output voltage Total Harmonic Distortion (THD) | 5% |
| Input current Total Harmonic Distortion (THD) | 5% |
| Noise level | 54.5 dB |
| Web-based management | Yes |
| Ports & interfaces | |
| AC outlet types | Hard Wire 5-wire (3PH + N + G), Terminal |
| Power plug | Terminal |
| AC outlets quantity | 2 AC outlet(s) |
| SmartSlot | Yes |
| Battery | |
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery voltage | 192 V |
| Battery life (max) | 5 year(s) |
| Design | |
| Form factor | Tower |
| Product colour | Black |
| Display type | LCD |
| International Protection (IP) code | IP20 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 35 °C |
| Storage temperature (T-T) | -10 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 9000 m |
| Certificates | |
| Compliance certificates | RoHS |
| Certification | CE, EN/IEC 62040-1-1, EN/IEC 62040-2, EN/IEC 62040-3, IEC 61000-4-5, IEC 62040-2, TUV, VFI-SS-111 |
| Packaging content | |
| Manual | Yes |
| Quick installation guide | Yes |
| Weight & dimensions | |
| Width | 400 mm |
| Depth | 950 mm |
| Height | 1300 mm |
| Weight | 218 kg |
| Packaging data | |
| Software CD | Yes |
| Package width | 800 mm |
| Package depth | 965 mm |
| Package height | 1440 mm |
| Package weight | 243 kg |
