NETGEAR GS105PP

GS105PP-300EUS - 606449174717

NETGEAR GS105PP Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Desktop/Wall-Mounting Grey

Brand: Netgear
Product code: GS105PP-300EUS
SKU: O8ATFB0XRSXTP
EAN/GTIN: 606449174717

5 x Gigabit Ethernet ports with PoE+
Plug and play switch, no management required
Energy Efficient Ethernet for maximum power savings
Fanless and silent
Desktop or wall-mount

€126.77 (Inc. VAT)

Sold Out

(Delivery 2-4 working days)

Product Info

5-Port, Gigabit, PoE+, 63 W, 128 KB, 2K, 0-40°C, Grey, 158 x 101 x 27 mm, 0.40 kg

NETGEAR GS105PP. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 5. Full duplex. MAC address table: 2000 entries. Networking standards: IEEE 802.1p, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az. DC input voltage: 54 V. Power over Ethernet (PoE). Form factor: Desktop/Wall-Mounting

POWER-OVER-ETHERNET

4 PoE+ ports delivering up to 30W per port with a 83W total power budget for wireless APs, IP Cameras, IP Phones and much more.

PLUG-AND-PLAY

Simple set up with no software to install or configuration needed

NON-BLOCKING SWITCHING

Non-blocking switching architecture for maximum throughput at wire speed

FANLESS DESIGN

Silent operation makes this switch perfect for noise-sensitive environments

VERSITILE MOUNTING OPTIONS

Install your switch on your desktop or mount it to your wall with the hardware provided in the box

ENERGY EFFICIENT

Energy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption when there is light traffic on an active port or when there is no link or no activity detected Flex PoE

Specifications

Management features

Switch type Unmanaged

Quality of Service (QoS) support Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity 5

Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)

Network

Networking standards IEEE 802.1p, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az

10G support No

Copper ethernet cabling technology 1000BASE-T, 100BASE-T, 10BASE-T

Port mirroring Yes

Full duplex Yes

Flow control support Yes

Link aggregation Yes

Broadcast storm control Yes

Rate limiting Yes

VLAN support Yes

Data transmission

MAC address table 2000 entries

Store-and-forward Yes

Jumbo frames support Yes

Jumbo frames 9216

Packet buffer memory 0.128 MB

Security

DHCP features DHCP client

IGMP snooping Yes

Design

Rack mounting No

Stackable No

Form factor Desktop/Wall-Mounting

Product colour Grey

Housing material Metal

LED indicators Activity, Link, PoE, Power, Speed, Status

Performance

Fanless Yes

Mean time between failures (MTBF) 4113947 h

Power

Power source AC/DC

Power supply included No

DC input voltage 54 V

Input current 1.66 A

Power consumption (max) 67.5 W

Power over Ethernet (PoE)

Power over Ethernet (PoE) Yes

Power over Ethernet (PoE) ports quantity 4

Power over Ethernet (PoE) power per port 30 W

Total Power over Ethernet (PoE) budget 83 W

Other features

Bandwidth 10 Gbit/s

Operational conditions

Operating temperature (T-T) 0 - 40 °C

Storage temperature (T-T) -20 - 70 °C

Operating relative humidity (H-H) 0 - 90%

Storage relative humidity (H-H) 0 - 95%

Operating altitude 0 - 3000 m

Heat dissipation 3.24 BTU/h

Weight & dimensions

Width 158 mm

Depth 101 mm

Height 27 mm

Weight 400 g

Packaging content

Quick start guide Yes

Certificates

Compliance certificates CB, CE, Federal Communications Commission (FCC)

Certification CB, CE LVD, CSA
