NETGEAR GS105EP

GS105EP-100EUS - 606449174670

NETGEAR GS105EP Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey

Brand: Netgear
Product code: GS105EP-100EUS
SKU: 4VP5O953IH5ET
EAN/GTIN: 606449174670

5 x Gigabit Ethernet ports with 4 x PoE+ ports
Plug-and-play with fundamental network management features
QoS and VLAN management
Fanless and silent
Desktop or wall-mount

€107.79 (Inc. VAT)

Sold Out

(Delivery 2-4 working days)

Product Info

5-Port, Gigabit, 63 W, 2K, 1.5 MB, 0-40°C, Grey, 158 x 101 x 27 mm, 0.39 kg

NETGEAR GS105EP. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 5. Full duplex. MAC address table: 2000 entries. Networking standards: IEEE 802.1p, IEEE 802.3az. Power over Ethernet (PoE)

EASY POE CONTROLS

Manage PoE prioritization, PoE power limit per port, PoE scheduling and more for advanced control over all PoE-powered devices

GIGABIT ETHERNET

5 ports provide gigabit Ethernet connectivity to your devices

VLANS

Port-based and 802.1Q-based network separation into smaller groups for more secure and efficient use of network resources

FANLESS DESIGN

Silent operation makes this switch perfect for noise-sensitive environments

VERSATILE MOUNTING OPTIONS

Place your switch on your desktop or mount it to your wall with the hardware provided in the box. Silent operation makes this switch perfect for noise-sensitive environments

ENERGY EFFICIENT

Energy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption when there is light traffic on an active port or when there is no link or no activity detected

Specifications

Management features

Switch type Unmanaged

Quality of Service (QoS) support Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity 5

Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)

Network

Networking standards IEEE 802.1p, IEEE 802.3az

Port mirroring Yes

Full duplex Yes

Flow control support Yes

Rate limiting Yes

Virtual LAN features Port-based VLAN

Data transmission

MAC address table 2000 entries

Jumbo frames support Yes

Jumbo frames 9216

Packet buffer memory 1.5 MB

Security

DHCP features DHCP client

IGMP snooping Yes

Password protection Yes

Queue scheduling algorithms Strict Priority Queue (SPQ), Weighted Round Robin (WRR)

Multicast features

Multicast support Yes

Number of multicast groups filtered 128

Design

Stackable No

Product colour Grey

Housing material Metal

LED indicators Activity, Link, PoE, Power, Speed, System

Safety UL listed (UL 1950)/CUL, CB

Performance

Noise level 0 dB

Mean time between failures (MTBF) 1164104 h

Power

Power source AC/DC

Power consumption (typical) 4 W

Power consumption (max) 74.7 W

Power over Ethernet (PoE)

Power over Ethernet (PoE) Yes

Power over Ethernet plus (PoE+) ports quantity 4

Power over Ethernet (PoE) power per port 30 W

Total Power over Ethernet (PoE) budget 63 W

Other features

Connectivity technology Wired

Power requirements 12V, 1.0A

Electromagnetic emissions CE mark, FCC 15 B, EN 55022 (CISPR 22) B, VCCI B, C-Tick

Networking features Gigabit Ethernet

Connectivity LEDs Y

Operational conditions

Operating temperature (T-T) 0 - 40 °C

Storage temperature (T-T) -20 - 70 °C

Operating relative humidity (H-H) 0 - 90%

Storage relative humidity (H-H) 0 - 95%

Operating altitude 0 - 3000 m

Weight & dimensions

Width 158 mm

Depth 101 mm

Height 27 mm

Weight 390 g

Packaging content

Quick start guide Yes

Manual Yes

Certificates

Compliance certificates BSMI, CE, Federal Communications Commission (FCC), KC, VCCI
